Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition

Error no. Error description

D16878-9909

D17056-1909

D17183-201

Sometimes the conveyor of X4i S and X4 S placement machines did not

transfer the board to the next station.

D16879-2111 eSW: Software hung up after an error when moving into input section.

D16901-7079 Machine hardware could not be initialized.

D17183-32 Calibrated table position was lost after reboot.

Table 10-1: Corrected errors 706.1 SP2 station software

Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition

10.2 706.1 SP1 Station Software

Station software version 706.1 SP1 contains all the error corrections of the previous versions

701.xx – 706.1. Additionally, the following errors have been corrected in this version:

Error no. Error description

D1-68758343

D1-71144501

D1-81901140

LBO stopper was not operable in the I/O menu.

D1-75873801 Tape cutter did not cut, if only DATA I/O Roadrunner was available at the

location.

D1-77216101

D1-77750755

After that two conveyor lanes ran, only one conveyor lane ran during

production. The board in the input section was not moved into the machine.

D1-77938809

D1-75629551

D1-78186801

D16683-3718

The boards were not transported due to an error in the conveyor controller.

D1-78346955 Conveyor problem: the board moved in up to the light barrier, then it was

recognized as "clambing".

D1-79950501 The software sporadically hung up after a board fiducial error.

D1-81283201 The PCB barcode was not passed on from one module to another.

D1-81760302 Error during readout of the statistics data.

D1-81826901 eSW: Wrong sequence within the axis led to non-operating machine.

D1-81835901 No update at the station by Line Control after fiducial settings were changed

on a board.

D1-81888301

D1-81901901

D1-82777543

Error message: Twin segment down, if emergency stop loop was interrupted

and the stop button was not pressed before.

D1-81975778 The machine displayed a message that nozzle 532 was not referenced.

D1-82132701 eSW: CP20a heads were sporadically recognized as new heads or the

component sensor values were still not valid after calibration.

D1-82153375

D1-82151202

All support pins were put back into the magazines and set on the table again

after "Start" was pressed after "Stop".

D1-82160701

D1-82169801

Machine stopped because of too many repeated errors at segment 5.

D1-82569701 Error in the lamp indicator controller of the white lamp indicator at "Warning".

D1-82588401 Faulty flashing of green lamp indicator: short flashing instead of normal

flashing.

Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition

Error no. Error description

D1-82588449 Flash behavior of the green lamp indicator changed during product change.

D1-82604011 Unhandled Exception within SirioConsole.exe.

D1-82620574 Unknown placement state.

D1-82620901 Teaching the zero point of the machine was inverse to the Vision display.

D1-82633901 The "Loading board" function was aborted with an error message for the

embedded software.

D1-82747057 After timeout for the DP axis, the station had to be rebooted.

D1-82759001

D1-82597601

Coplan MFU did not function on an SX1/SX2 placement machine.

D1-82793701 Conveyor lane 2 was locked although a job was defined.

D1-82802953 Sporadically, the GUI did not start after a reboot.

D16901-4109 eSW: 12/16mm X smart feeders sporadically reported foil broken errors

although there was no foil torn.

Table 10-2: Corrected errors 706.1 SP1 station software
