Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition
47
Component range
for Twin Head
With type 25
component camera
(Stat. P&P 16 x 16
mm digital)
With default type 33
component camera (Stat.
P&P 55 x 45 mm digital)
With type 36 component
camera (Stat. P&P 32 x
32 mm digital)
0201 through 16 x 16
mm
0402 through 55 x 45 mm 0603 through 32 x 32 mm
Nozzle types 5 xx (standard), 4 xx + adapter, 8 xx + adapter, 9xx + adapter
Table 7-5: Component range Twin Head
Component range
for VHF P&P head
With type 25 component camera
(Stat. P&P 16 x 16 mm digital)
With default type 33 component
camera (Stat. P&P 55 x 45 mm
digital)
0201 through 16 x 16 mm 0402 through 55 x 45 mm
Nozzle types 508
Table 7-6: Component range VHF P&P head
Component range for
C&P12 head
With default type 28 component
camera (C&P 18,7 x 18,7 mm
digital)
With type 30 component camera
(C&P 27 x 27 mm digital)
0402 through 18.7 x 18.7 mm 0201
*)
through 27 x 27 mm
Nozzle types 30xx
Table 7-7: Component range C&P12 head
*)
0201 components can only be placed restrictively.
Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition
48
8 SIPLACE Software Environment
8.1 SIPLACE Pro Programming System Version 10.1 SP1
The SIPLACE Pro programming system Version 10.1 SP1 supports the SIPLACE X-series, SX-
series and DX-series placement machines with the 706 station software version.
Compatible mode: SIPLACE Pro Version 9.3.
NOTICE
For a detailed description of the programming system, see the SIPLACE Pro version
description and the online help system.
8.2 SIPLACE OIS Version 10.1
Software version 10.1 of the monitoring system SIPLACE OIS supports the SIPLACE X-series, SX-
series and DX-series placement machines.
Compatible mode: OIS Version 9.3.
NOTICE
A detailed description can be found in the software description "Getting started with OIS"
and the online help system for OIS.
8.3 SIPLACE Setup Center Version 5.1 SP1
Software version 5.1 SP1 of the SIPLACE Setup Center supports the SIPLACE X-series, SX-series
and DX-series placement machines.
Compatible mode: SIPLACE Setup Centen Version 4.2.
NOTICE
A detailed description can be found in the software description "Getting started with
Setup Center" and the online help system for Setup Center.
Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition
49
8.4 SIPLACE Traceability Version 3.5
Software version 3.5 of SIPLACE Traceability supports the SIPLACE X-series, SX-series and DX-
series placement machines.
Compatible mode: SIPLACE Traceability 3.3.
NOTICE
A detailed description can be found in the “Traceability User Guide".
