Consumables, Spare and Wear Parts, Tools Minor and Major Maintenance for X Series Machines 22 Maintenance Manual SIPLACE X Series Tools Item No. Supplie d in the service box ESD wriststrap TYP.OK/WRS 00320279-xx Set of P…

Consumables, Spare and Wear Parts, Tools

Minor and Major Maintenance for X Series Machines

Maintenance Manual SIPLACE X Series 21

Consumables, Spare and Wear Parts, Tools

3 Consumables, Spare and Wear Parts, Tools

The following lists contain all necessary consumable materials, wear and spare parts plus tools for

performing maintenance tasks to the machine and placement heads.

Minor and Major Maintenance for X Series Machines

3.1 Minor and Major Maintenance for X Series Machines

For maintenance work to the SIPLACE X series we recommend using the "Service box for X and SX

series [03079042

xx]".

Consumables Item No. Supplied in the

service box

OIL Interflon Fin Super (Teflon oil) 03017760-xx

SIPLACE cleansing tissue 00315253-xx X

Klüberplex BEM 34-132 grease 00374565-xx X

Protective latex gloves 00372972-xx

Rust prevention spray WD40, 400 ml 00325833-xx

Sheet of DIN A4 paper and adhesive tape

Lint-free cloth, KM wipe 03082092-xx

Microfiber cloth for cleaning optical assemblies

Ethanol

Wear parts Item No. Supplied in the

service box

Filter element 40 µm 03003717-xx X

Filter element 5 μm

HSxx / D1 / D2 / D4 / SX series /

X series from March 2008 pneumatic valve [03062274-xx]

(for [03060279-xx] pneumatic unit)

03050213-xx X

Replacement filter for 5 μm compressed air filter for pneumatic

valve

X series up to SN B089 [03004680-xx]

(for [03004151-xx] pneumatic unit)

03038979-xx

Filter element for 5 μm filter (new) for pneumatic valve

X series from SN B090 [03038691-xx]

(for [03038058-xx] pneumatic unit)

03039182-xx

Fan unit for intake air filter 00376006-xx

Felt filter RFF-92-10 (92x92 mm) (for size supplied:

1000x1500x10 mm or air filter for Y axis (120x120 mm)

03006574-xx

03053286-xx

Filter unit 03003425-xx

SIPLACE X4I only: Y axis air filter for 120 mm fan (for protective

cover)

03053286-xx

Consumables, Spare and Wear Parts, Tools

Minor and Major Maintenance for X Series Machines

22 Maintenance Manual SIPLACE X Series

Tools Item No. Supplied in the

service box

ESD wriststrap TYP.OK/WRS 00320279-xx

Set of Phillips screwdrivers

SIPLACE OPERATOR KIT 00349303-xx

Scissors 00378524-xx

Brush 00378523-xx

Tweezers 00378525-xx

Electronic screwdriver, Phillips 00378527-xx

Electronic screwdriver, slotted 00378526-xx

Vacuum cleaner

Waste bin

Oil stone / Elasto abrasive cleaning agent

Grease gun with nozzle for X axis (volume applied: approx. 0.13 g) 00374564-xx X

Grease gun with hose for Y axis (volume applied: approx. 0.4 g) 00374563-xx X

A high-precision set of scales (recommended minimum measuring

accuracy: 1 g)

Spare parts Item No. Supplied in the

service box

Gas spring 560N (for hood over 2 gantries) 03036763-xx

Gas spring 510 N (for hood over 1 gantry) 03039170-xx

Consumables, Spare and Wear Parts, Tools

Minor and Major Maintenance for CPP, C&P6/12, C&P20A and TwinHead

Maintenance Manual SIPLACE X Series 23

Minor an d Major M aintenance for CP P, C&P6/12, C&P20 A and TwinHead

3.2 Minor and Major Maintenance for CPP, C&P6/12, C&P20A and

TwinHead

For maintenance work performed on the TwinHead, CPP and C&P20(A) heads we recommend using

the "Starter kit for CPx and TwinHead maintenance" [03071171

03].

We also recommend using additional multipettes [03078989

xx], so that the combitips do not need to be

changed when lubricating multiple heads.

Consumables Item No. Supplied in

starter kit

03071171

CPP CP20A TH CP6/12

OIL Interflon Fin Super (Teflon oil) 03017760-xx X X

Lint-free cloth, KM wipe 03082092-xx X X X

Microfiber cloth for cleaning optical

assemblies

X X X

Ethanol X X X

Lubcon Thermoplex ALN 1001/00,

50ml (blue)

03078556-xx X X X

ISOFLEX Topas NCA 5051 50ml

(green)

03078517-xx X X

Klüber oil GEM 1 220N 30ml (yellow) 03079640-xx X X

Klüberalfa DH 3-100, 50ml (black) 03078928-xx X X X

NYE Synthetic Oil 200A, 50 ml (white)

(only for C&P20)

03078548-xx X X

Maintenance labels CP20 (pack of 10) 03067486-xx X X X

CD marker Edding 8400 03070076-xx X X X

SIPLACE cotton wool buds, lint-free 00352931-xx X X X

Distilled water X X X

Compressed air X X X

Whiteboard cleaners, set of 10 03070074-xx X X

Protective latex gloves 00372972-xx X

Cotton gloves virgin, size 8 00359087-xx X

Microtips medium precision applicator

(cotton buds)

03020860Sxx X

ISOFLEX TOPAS, NCA 52 tin 1 kg/

tube 50 g

00330850-xx X

UNISILKON L250L grease 00310259-xx X
