Page SAMSUNG TECHWIN 339 SP1 Bypass L/R Option Bracket Block Diagram (1/2) SP1 OPTION NO. P ART NO. P ART NAME Q'TY Old No. Sto ck Apply Reference 1 J9167247 0C LCV_BP_BEL T_DRV_C ABLE_ASSY 1 J91672470A 2 J9167246 8…
Page
SAMSUNG TECHWIN
338
SP1
Bypass L/R Option Bracket Block Diagram (1/2) SP1 OPTION
Page
SAMSUNG TECHWIN
339
SP1
Bypass L/R Option Bracket Block Diagram (1/2) SP1 OPTION
NO. PART NO. PART NAME Q'TY Old No. Stock Apply Reference
1 J91672470C LCV_BP_BELT_DRV_CABLE_ASSY 1 J91672470A
2 J91672468B LEFT_SHUTTLE_DRV_CABLE_ASSY 1 J91672468A
3 J91672401B CVCB_P3_CABLE_ASSY 1 J91672401A
4 J91671978B LCV_BP_BELT_EXT_CABLE_ASSY 1 J91671978A
5 J91671974A LEFT_SHUTTLE_EXT_CABLE_ASSY S1_MD028 1
6 J91671961A LEFT_CV_FR_BELT_EXT_CABLE_ASSY S1_LCV006 1
7 AM03-013543A LEFT_CV_REAR_BELT_EXT_CABLE_ASSY S1_LCV0 1 J91671963A
8 J91672009B BYPASS_CV_FRONT_MOTOR_CABLE_ASSY 1 J91672009A
9 J91671960A LEFT_CV_FRONT_MOTOR_CABLE_ASSY S1_LCV005 1
10 J91671962A LEFT_CV_REAR_MOTOR_CABLE_ASSY S1_LCV007 1
11 J91671956A LEFT_SHUTTLE_MOTOR_CABLE_ASSY S1_LCV001 1
12 AM03-004885A BYPASS_CV_KZAR_BELT_EXT2_CABLE_ASSY_ S1_BP016 1
Page
SAMSUNG TECHWIN
340
SP1
Bypass L/R Option Bracket Block Diagram (2/2) SP1 OPTION
