1 Introduction
1.1 Brief description
Bedienungsanleitung OSC Package User Guide OSC-Paket 11/2018 55
1 Introduction
This guide gives an overview of the contents of the ASM OSC package. Here you will find all key
information needed for working with the features of the ASM OSC Package.
1.1 Brief description
Components with irregular component shapes outside the standard range are referred to as Odd
Shape Components – (OSC). When handling odd shape components, the trend is towards in-
creased automation in the placement line with the following target:
●
Reduce manufacturing costs
●
Maximize product quality by avoiding human error factors
●
Reduce manual workstations at the line and thus optimize the floor size
From R16-2, SIPLACE supports new features for odd shape components that have been collected
into the licensed OSC Package option. This extends the range of components that can be
assembled by a SIPLACE machine.
Following features are supported by the OSC Package from R16-2:
●
Improved placement of snap-in components
●
Stereo Measurement for THT Pins
●
Customer-specific Pattern Features
●
Special position evaluation
●
Support to find best acceleration (can be set at the station, only)
●
Increased placement force of Twin VHF placement head to 100 N
Additionally, the following features, options and improvements are supported from R18-2:
●
Improved placement of components with centering pins with the CPP and TH placement
heads (Pin in Paste height check)
●
Improved teaching of snap-in components
●
Stereo measurement for Gullwing and Pattern Features lead group types
●
4x image capture measurement parameter in the stereo measurement
●
Automatic illumination optimization for Non-standard and Connector component types
●
Placement of an exceptionally high component (1 use case)
●
Increased placement force for TH placement head to 30 N
A detailed description of the single features can be found in chapter 4 "Working with the OSC Fea-
tures" [}61].
1.2 General information
1.2.1 Legend
This document uses the following symbols and notes for your convenience.
Words in bold/italic print These refer to dialogs, dialog fields, menu items, and com-
mands.
Step ... Includes all actions to do with a particular dialog. A dialog may
be composed of several actions (→).
► Requires an action (e.g. mouse click, open file)
Indicates a warning. The information is essential for successful
working.
Indicates explanatory information.
1 Introduction
1.2 General information
56 Bedienungsanleitung OSC Package User Guide OSC-Paket 11/2018
1.2.2 ASM on the World Wide Web (WWW)
Log in to our ASM® homepage at http://www.asm-smt.com.
► You can choose between the German and English version.
The different sections contain information about our products, services and contact persons.
In addition, registered customers can also access the MySIPLACE user group. Here you can call
up special information about our placement systems, e.g.
●
technical documentation
●
technical information
●
Spare parts lists etc.
Registration for theMySIPLACE user group is very simple:
► Click on the MyASM button at the head of the web site and then on the
Register link.
► Fill in the registration form and send it off to us.
Soon afterwards, you will receive your access authorization with user name and password.
2 Scope of delivery
Bedienungsanleitung OSC Package User Guide OSC-Paket 11/2018 57
2 Scope of delivery
The OSC package needs a license and is delivered together with this User Guide in the
OSCPackage – Machine Connection license package, item no. [00117263-xx].
