3 Prerequisites
The necessary system requirements for the OSC package correspond to the system requirements
for SIPLACE Pro and are described in the SIPLACE Pro Version Description,
item no. [00198612-xx] .
3.1 Software Requirements
The following software requirements must be met for the released features of R16-2:
●
SIPLACE Pro from Version 14.0 (R16-2)
●
Station software from Version 710.0 (R16-2)
●
SIPLACE Vision from Version 5.4.1 (R16-2)
The following software requirements must be met for the released features of R18-2:
●
SIPLACE Pro from Version 16.0 (R18-2)
●
Station software from Version 712.0 (R18-2)
●
SIPLACE Vision from Version 5.6.1 (R18-2)
3.2 Hardware Requirements
The following hardware requirements must be met for the released features of R16-2:
Function Hardware
Improved placement of snap-in components Placement heads: : Twin VHF
Smart Pin Support is recommended
Stereo Measurement for THT Pins Placement heads: CPP, TH, TH HF,
Twin VHF
Camera types: SST33, SST25
Customer-specific Pattern Features Placement heads: All
Special position evaluation Placement heads: All
Support to find best acceleration Placement heads: All
Increased placement force for Twin VHF placement
head to 100 N
Placement head: Twin VHF
Can only be used with function status
-03!
Smart Pin Support is recommended
The following hardware requirements must be met for the released features of R18-2:
Function Hardware
Improved placement of components with centering pins
(Pin in Paste height check)
Placement heads: CPP, TH, Twin VHF
Smart Pin Support is recommended
Improved teaching of snap-in components Placement head: Twin VHF
Stereo measurement for Gullwing and Pattern
Features lead group types
Placement heads: CPP, TH, TH HF,
Twin VHF
Camera types: SST33, SST25
Measurement parameter 4x image capture as option in
the stereo measurement
Placement heads: CPP, TH, TH HF,
Twin VHF
Camera types: SST33, SST25
Automatic illumination optimization for Non-standard
and Connector component types
Placement heads: All
3 Prerequisites
3.2 Hardware Requirements
60 Bedienungsanleitung OSC Package User Guide OSC-Paket 11/2018
Function Hardware
Placement of an exeptionally high component
(1 use case)
Placement machine: SIPLACE SX V2
Single conveyor
Placement head: only Twin VHF or
Twin VHF and Twin VHF or
Twin VHF and CPP in higher position
One component of type SMT;
Height: max. 46 mm
or
One component of type THT (e.g. Con-
nector or Inductance);
Height: max. 46 mm without protruding
elements which disappear into the board
after placement (e.g. centering pins), 50
mm with protruding elements
Increased placement force for TH placement head to
30 N (as for TH HF)
Placement head: TH
Smart Pin Support is recommended
