Notes: Part 8 Chapter 2 Feeder Maintenance Edition 1.0 8-2-8 CP-6 Series Mechanical Reference

Select the device with the cursor and press the F7 key (error).

The following information will be displayed.

Production Data Display 2/2

Refer to the error code display for information on the error codes shown in the dashed

frame.

When MAINTENANCE/DEVICE is chosen, and the device generating the error selected,

it is possible to check the detailed error information, which can be used to determine if

an inspection is required.

Caution : These error results also include errors due to defective part shapes and defective

parts tape. For this reason, you should check both feeder and parts for devices which

suffer from low operating rates.

ERROR CODE :

The following error codes are representative of pick-up errors. For other errors, check the

ERROR CODE DISPLAY.

12040403 No part in nozzle

1CA0A007-1CA0A009 Error due to on-end part during pick-up

12040407 Error due to angle offset during part pick-up

MAINTENANCE - DEVICE

LINE : FUJI MC : CX0900 PROGRAM : EVALUATION. WO8xP02.D1

D_NO.

001

D_COMMENT

: RESISTOR2125T04.3

1CA0A009 26

TOTAL 150

(F1) (F2) (F3) (F4) (F5) (F6) (F7) (F8)

*----------------------------------------------------------------------------------------------------*

ERROR CODE

ERROR

1CA0A008 40

1CA0A007 12

12040403

12040407

end

CP6M8082

Part 8 Chapter 2 Feeder Maintenance

Edition 1.0 8-2-7 CP-6 Series Mechanical Reference

Notes:

Part 8 Chapter 2 Feeder Maintenance

Edition 1.0 8-2-8 CP-6 Series Mechanical Reference

3. Troubleshooting

Note : This section covers the WC type feeder.

In general, feeders which require maintenance are those with low pick-up ratios, or

which cause high machine stop ratios.

The causes of these problems can be grouped into three major categories :

A Excessive top film take-up errors

B Excessive parts tape feed errors

C Low pick-up ratio, but not accompanied by the above

3.1 Inspection Items and Methods

A Excessive top film take-up errors

A-1 Is the top film set correctly?

Refer to section 1.4 “Loading W8, W12 mm Feeders” through 1.6 “Loading W32

Paper Feeder” of this chapter, and check that the top film is correctly set.

A-2 Is the top film take-up reel cover tight?

Weak on the cover lock can make it difficult for the lock to hold. In this case,

replace the top film take-up reel cover.

If the problems remains after replacement, then wear on the shaft-side reel lock is

probably the cause. Replace the top film take-up reel entirely. Note that the shaft-

side reel cannot be purchased alone.

A-3 Is the tape leaf slit clean?

If there is any material caught in the tape leaf, clean it with an air gun. Be sure to

clean the tape leaf every time the parts reel is changed.

Checking the Tape Leaf

Clean top and bottom surfaces

CP6M8083

Part 8 Chapter 3 Troubleshooting

Edition 1.0 8-3-1 CP-6 Series Mechanical Reference
