A-2
Appendix
1.2 Power connection terminals
Thepowerconnectionterminalsarelocatedinsidethelowerrightpanelonthefrontofthemachine.Connect
thepowercableleadsasshownbelowtotheL1,L2,L3andgroundterminal(PE)onthepowerterminalblock.
n
Power supply specifications
Model name Power Frequency Power capacity
YS12P
3-phase AC 200/208/220/240/380/400/416V (±10%) 50/60Hz
3.6KVA
YS12F 4.3KVA
YG12F 4.3KVA
Power connection terminals
Main breaker
Power input terminals
(L1, L2, L3) and ground terminal
Power cable
Secure the clamps at two
positions
Wire through this clamp plate
53433-M7-00
L1
L2
L3
PE
L=100mm
Power cable example
Fork-tongue crimp terminal
Ring-tongue crimp
terminal
53434-M7-00
c

Use a power cable whose conductor cross-section area is greater than 3.5mm
2
.
w
WARNING


A-3
Appendix
2. Warranty
The machine you have purchased is warranted against malfunctions as described below.
n
Warranty description:
Ifafailureorbreakdownoccursduetodefectsinworkmanshipormaterialsusedtomanufacturethismachinewithin
oneyearor5,000hoursofoperation(whichevercomesfirst)aftertheincominginspectioniscomplete,thenYAMAHA
willrepairthedefectivepartsfreeofcharge.
n
Warranty period
Thewarrantyperiodendswhenanyofthefollowingapplies:
1.Afteroneyearhaselapsedfromthetimeofinstallation.
2.After5,000hoursofoperation.
n
Items not covered by the warranty
Thewarrantydoesnotcoveranyofthefollowingconditions:
1.Damageasaresultofdeteriorationduetoageorwear(e.g.,normaldiscolorationofpaintedorplatedsurfaces,wear
ofreplaceableparts,etc.).
2.Incidentsassociatedwithsensoryperceptionswhichhavenobearingonthequalityorfunctionofthemachine(e.g.,
signalsoundsemittedbythecontroller,rotatingsoundsofthemotor,etc.).
3.Damagecausedbytheuserenvironment(e.g.,impuritiesintheairsupply,dust,debrisandoilmistinthemachine).
n
Exception to warranty repairs
Warrantyrepairswillnotbemadeifdamageiscausedbythefollowing:
1.Earthquakes,typhoons,floods,lightning,accidentsorfires,othernaturalorman-madedisaster.
2.ModificationsorconversionsnotapprovedbyYAMAHAoritsdealers.
3.Useofnon-genuineparts,greasesorlubricants.
4.Lackofpropermaintenanceandinspectionprocedures.
5.Maintenancehandledbysomeoneotherthantheapproveddealers.
6.Damageormalfunctionduetochangesinthemachineinstallationlevelthatmaybecausedbychangesinthe
foundationorsurroundingenvironment.
7.Themachinewasmodifiedorchangedinspecificationsaftertheincominginspectioniscomplete.
8.WhendefectivepartsreplacedfreeofchargewerenotreturnedtothelocationspecifiedbyYAMAHAorYAMAHA
salesrepresentativeswithin30days.
n
Note on network connections
ApreconditionfornetworkconnectionswiththeYAMAHAsurfacemountersandrelatedmachinesisthatsuch
connectionswillbeusedinclosednetworkscomprisedofaYAMAMHAsurfacemounter(orrelatedmachine)andanoff-
linePC.Thecustomermusttakeresponsibilityforconnectionstocompanyin-housenetworksandtoexternalnetworks.
PleaseacknowledgethatYAMAHAcanbearabsolutelynoresponsibilityfornetworksconfiguredbyotherthanjusta
YAMAMHAsurfacemounter(orrelatedmachine)andoff-linePCnorcanacceptresponsibilityforproblemsoccurring
duetonetworksettingsandconnections.
n
About USB memory devices
•UsetheUSBmemorydevice(suppliedwiththemachineorpurchasedfromYAMAHAsalesreps)specifiedby
YAMAHAMotorsCo.,Ltd.DonotuseanyothertypeofUSBmemorydevicewithYAMAHAsurfacemountersand
relatedmachines.AnyproblemsarisingfromusingotherthanthespecifiedUSBmemorydevicearenotcoveredby
ourwarranty.
•DonotconnectanyUSBdeviceotherthanthespecifiedUSBmemorydevicetotheUSBportonthemachine.Ifa
devicedriverforawrongdeviceisinstalled,thenthemachinemightnotworkcorrectly.Wetakenoresponsibilityfor
anyproblemscausedbyconnectingawrongorinappropriatedevice.
MAINTENANCE MANUAL
Nov. 2009 Version 1.00
© YAMAHA MOTOR CO., LTD. IM Operations
All rights reserved. No part of this publication may be
reproduced in any form without the permission of
YAMAHA MOTOR CO., LTD.
Information furnished by YAMAHA in this manual is believed to
be reliable. However, no responsibility is assumed for possible
inaccuracies or omissions. If you find any part unclear in this manual,
please contact YAMAHA or YAMAHA sales representatives.
