4-9
4
How to replace consumable parts
4.4 Conveyor W-axis linear guide and ball screw
W-axis lubrication points
W-axis ball screw
W-axis ball screw
W-axis linear guide
W-axis linear guide
W-axis hexagon spline
Grease gun:
Manual lubrication:
Lubrication section Lubrication point Interval Procedure
Linear guide 2
Once every
6 months
Grease gun: Standard nozzle
Ball screw 2 Grease gun: Standard nozzle
Hexagon spline 1 Manual lubrication
53438-M7-00
4.5 Head spline shaft
Z-axis lubrication points
Grease gun:
Manual lubrication:
Z-axis spline shaft
Lubrication section Lubrication point Interval Procedure
Z-axis spline shaft 5 3 months Manual lubrication (thin coat)
53439-M7-00
Appendix
Appendix
Contents
1. Specifications A-1
1.1 Air regulator unit A-1
1.2 Power connection terminals A-2
2. Warranty A-3
A-1
Appendix
1. Specifications
1.1 Air regulator unit
Theairregulatorforcontrollingtheairpressuretothepneumaticunitsofthemachineislocatedbehindthe
frontlowerleftpanel.Adigitalpressuregaugeisprovidedonthefrontleftofthemachine.Theairpressure
mustbesettotheoptimumlevel.
Air pressure setting
for machine
YS12P
YS12F
YG12F
Air pressure regulator and pressure gauge
Source air connector
Air pressure regulator
(For machine)
Air pressure
regulator
(For YG12F head
assembly)
For head assembly
setup
For machine setup
Air supply/shutoff
switch (valve)
Pressure-drop
detection level
53427-M7-00
n
Supply air pressure
Thisisthepressureofthesourceairsuppliedtothemachine.Beforesettingtheairpressurewiththeairregulator,make
surethatthissupplyairpressureisinthefollowingoptimalrange.
YS12P,YS12F:0.45MPato0.70MPa
YG12F:0.60MPato0.70MPa
n
Digital pressure gauge
Showsthesupplyairpressure(upperreading)andpressure-dropdetectionlevel(lowerreading).Anormalpressurevalue
isshowningreen,andapressurevaluelowerthanthepressure-dropdetectionlevelisshowninred.
n
Air pressure setting and pressure-drop detection level
• YS12P, YS12F
Airpressuresettingformachine(upperreading):0.40MPa
Pressure-dropdetectionlevel(lowerreading) :0.33MPa
• YG12F
Airpressuresettingformachine(rightupperreading) :0.55MPa
Pressure-dropdetectionlevel(rightlowerreading) :0.40MPa
Headsetuppressure(leftupperreading) :0.40MPato0.41MPa
Pressure-dropdetectionlevel(leftlowerreading) :0.33MPa
n
Air supply/shutoff switch (valve)
Turningthisswitchtotherightshutsoffairsupplyandexhaustsairthatremainsinsidethemachine.
n
Source air connector
Prepareanairhosewithaninnerdiameterofatleast8mmhavinga40SHsocket(NittoKoki,orequivalent),andconnect
ittothisconnector.Usedry,cleanairpassedthroughanairfilter.
