3-28
3
Periodic maintenance items
4. Six-month or one-year inspection
4.1 Cleaning the fiducial camera lighting unit (6-month inspection)
Thelightingunitmaybecomedirtyduetodustanddirt.Werecommendperiodiccleaningasexplainedbelow.
Toensuresafety,makesurethatthemachinepowerswitchisoffortheemergencybuttonispressedbefore
startingwork.
c


become unreliable.
c


of the lighting unit by the user will void the warranty.
n
Fiducial mark recognition camera
Thefiducialmarkrecognitioncameraismountedontheheadassembly.Cleanthelightingunitforthiscamera
asexplainedbelow.
• Cleaning method
Applyafewdropsoflenscleanertoalint-free
cleaningclothandwipethediffuserplateonthe
bottomofthelightingunit.
53337-L6-00
Wipe with cleaning cloth.
Lighting unit for fiducial mark camera
3-29
3
Periodic maintenance items
4.2 Checking the R-axis spline belt (1 year)
TherearetwoR-axissplinebelts.Checktheconditionofeachbelt.
n
R-axis spline belt checkpoints
•Isthebeltbecomingfrayedduetocracksandbeltwear?
•Isthebeltsplittingduetocracksordeterioration?
•Isthebelttensiontooloose?Isthebeltitselfloose?
c


cleaning of the spline belt by the user will void the warranty.
Spline for Head 1
Spline belt
R-axis belt (upper belt)
R-axis belt (lower belt)
Belt tensioner
Belt tensioner
Belt tensioner
Belt tensioner
R-axis motor
53345-L6-00
3-30
3
Periodic maintenance items
4.3 Cleaning and replacing the blow station filter (1 year) … option
Thissectiondescribeshowtocleanandreplacethefilterusedinthemachinesequippedwithablowstation
(option).
c


of the blow station by the user will void the warranty.
1
Turn off the air supply and the
power to the machine.
1. Quit the software and turn off the
machine power switch.
2. Turn the air supply/shutoff valve inside
the machine lower left panel to the right,
to stop the air supply.
53346-L6-00
2
Cut the cable ties on the filter.
Using a wire cutter or similar tool, cut the
cable ties that hold the filter unit inside the
blow station stand.
53347-L6-00
3
Disconnect the air hose from one
end of the filter unit and take out
the filter.
1. Disconnect the air hose from one end of
the in-line filter unit.
2. Remove the filter joint caps on both sides
of the filter by rotating them 90 degrees.
3. Pull the transparent case to remove it
and take out the filter.
53348-L6-00
4
Clean the filter.
Use an air blow gun to blow air through the
filter from the inside and from the outside. If
the filter is excessively dirty and cannot be
cleaned, replace it with a new filter.
• Inlinefilter(unit)
KGR-M9934-01X INLINE FILTER
• Filter
KGR-M9934-FOX FILTER, SPARE
Shutting off the air supply
Step 1
Air supply/shutoff valve
Cutting the cable tie
Step 2
Cable tie
Wire cutter In-line filter unit
Taking out the filter
Step 3
Air hose
Filter
Transparent filter case
In-line filter unit
Filter joint caps
