iv
Safety instructions
1.8 Keeping hands away from moving parts
Duringuseofthismachine,thecustomer’sequipmentandoperatingconditionsmightallowtheoperator’s
handstocomeintocontactwithmovingparts.
Usethefollowingsafetymeasureoptionstoavoidpossibledangerwhereopeningsorgapsarefoundonthe
machine.
n
Dummy feeder, One-stop cover (YS series machines)
Useadummyfeederasasafetymeasuretofillagapbetweentapefeeders.Installadummyfeederonthefeederbank
thesamewayasnormalSSfeedersinordertopreventhandsfromentering.
Prevention of hand entry
Dummy feeder, One-stop cover
Dummy feeder (Wide-size)
Dummy feeder (8mm-size)
One-stop cover (For feeder exchange carriage)
91203-L0-10
n
Dummy feeder (YG series machines)
Useadummyfeederasasafetymeasuretofillagapbetweentapefeeders.Installadummyfeederonthefeederplate
thesamewayasnormalfeedersinordertopreventhandsfromentering.
Dummy feeder
8mm
91203-M7-00
v
Safety instructions
n
Muzzle plate
Usetheseplatesasasafetymeasurefortheboardconveyorentranceandexitopenings.Eachplateismovable,soadjust
themountingpositiontomatchtheboardstobeproduced.
Muzzle plate
Upper muzzle plate
Lower muzzle plate
Board conveyance plane
91205-L0-00
Upper clearance Lower clearance Remarks
YS100/YS88 8.0 to 38.5mm 1.0 to 31.0mm From board conveyor plane
YS12, YS12P, YS12F, YS24
(YG12, YG12F)
5.0 to 20.0mm 4.2 to 39.2mm From board conveyor plane
YSP 0 to 6.6mm 0 to 26.4mm From board conveyor plane
vi
Safety instructions
2. Safety message
This section describes information you should always comply with to prevent unforeseen accidents that might
lead to injury of the operator and others or damage the machine. Hazards and injuries that might result from
ignoring safety instructions and operating the machine incorrectly are categorized as follows.
2.1 Safety message and categories in this manual
Thismanualusesthefollowingsafetyalertsymbols,signalwords,andformatstylesaccordingtothedegreeof
hazard.
n
Safety alert symbols and signal words
w
WARNING



c



n
NOTE
Gives helpful information or key points when operating the machine, in a simple and clear manner.
