A-1

Appendix

1. Specifications

1.1 Air regulator unit

Theairregulatorforcontrollingtheairpressuretothepneumaticunitsofthemachineislocatedbehindthe

frontlowerleftpanel.Adigitalpressuregaugeisprovidedonthefrontleftofthemachine.Theairpressure

mustbesettotheoptimumlevel.

Air pressure setting

for machine

YS12P

YS12F

YG12F

Air pressure regulator and pressure gauge

Source air connector

Air pressure regulator

(For machine)

Air pressure

regulator

(For YG12F head

assembly)

For head assembly

setup

For machine setup

Air supply/shutoff

switch (valve)

Pressure-drop

detection level

53427-M7-00

Supply air pressure

Thisisthepressureofthesourceairsuppliedtothemachine.Beforesettingtheairpressurewiththeairregulator,make

surethatthissupplyairpressureisinthefollowingoptimalrange.

YS12P,YS12F:0.45MPato0.70MPa

YG12F:0.60MPato0.70MPa

Digital pressure gauge

Showsthesupplyairpressure(upperreading)andpressure-dropdetectionlevel(lowerreading).Anormalpressurevalue

isshowningreen,andapressurevaluelowerthanthepressure-dropdetectionlevelisshowninred.

Air pressure setting and pressure-drop detection level

• YS12P, YS12F

Airpressuresettingformachine(upperreading):0.40MPa

Pressure-dropdetectionlevel(lowerreading) :0.33MPa

• YG12F

Airpressuresettingformachine(rightupperreading) :0.55MPa

Pressure-dropdetectionlevel(rightlowerreading) :0.40MPa

Headsetuppressure(leftupperreading) :0.40MPato0.41MPa

Pressure-dropdetectionlevel(leftlowerreading) :0.33MPa

Air supply/shutoff switch (valve)

Turningthisswitchtotherightshutsoffairsupplyandexhaustsairthatremainsinsidethemachine.

Source air connector

Prepareanairhosewithaninnerdiameterofatleast8mmhavinga40SHsocket(NittoKoki,orequivalent),andconnect

ittothisconnector.Usedry,cleanairpassedthroughanairfilter.

A-2

Appendix

1.2 Power connection terminals

Thepowerconnectionterminalsarelocatedinsidethelowerrightpanelonthefrontofthemachine.Connect

thepowercableleadsasshownbelowtotheL1,L2,L3andgroundterminal(PE)onthepowerterminalblock.

Power supply specifications

Model name Power Frequency Power capacity

YS12P

3-phase AC 200/208/220/240/380/400/416V (±10%) 50/60Hz

3.6KVA

YS12F 4.3KVA

YG12F 4.3KVA

Power connection terminals

Main breaker

Power input terminals

(L1, L2, L3) and ground terminal

Power cable

Secure the clamps at two

positions

Wire through this clamp plate

53433-M7-00

L=100mm

Power cable example

Fork-tongue crimp terminal

Ring-tongue crimp

terminal

53434-M7-00



Use a power cable whose conductor cross-section area is greater than 3.5mm

WARNING





A-3

Appendix

2. Warranty

The machine you have purchased is warranted against malfunctions as described below.

Warranty description:

Ifafailureorbreakdownoccursduetodefectsinworkmanshipormaterialsusedtomanufacturethismachinewithin

oneyearor5,000hoursofoperation(whichevercomesfirst)aftertheincominginspectioniscomplete,thenYAMAHA

willrepairthedefectivepartsfreeofcharge.

Warranty period

Thewarrantyperiodendswhenanyofthefollowingapplies:

1.Afteroneyearhaselapsedfromthetimeofinstallation.

2.After5,000hoursofoperation.

Items not covered by the warranty

Thewarrantydoesnotcoveranyofthefollowingconditions:

1.Damageasaresultofdeteriorationduetoageorwear(e.g.,normaldiscolorationofpaintedorplatedsurfaces,wear

ofreplaceableparts,etc.).

2.Incidentsassociatedwithsensoryperceptionswhichhavenobearingonthequalityorfunctionofthemachine(e.g.,

signalsoundsemittedbythecontroller,rotatingsoundsofthemotor,etc.).

3.Damagecausedbytheuserenvironment(e.g.,impuritiesintheairsupply,dust,debrisandoilmistinthemachine).

Exception to warranty repairs

Warrantyrepairswillnotbemadeifdamageiscausedbythefollowing:

1.Earthquakes,typhoons,floods,lightning,accidentsorfires,othernaturalorman-madedisaster.

2.ModificationsorconversionsnotapprovedbyYAMAHAoritsdealers.

3.Useofnon-genuineparts,greasesorlubricants.

4.Lackofpropermaintenanceandinspectionprocedures.

5.Maintenancehandledbysomeoneotherthantheapproveddealers.

6.Damageormalfunctionduetochangesinthemachineinstallationlevelthatmaybecausedbychangesinthe

foundationorsurroundingenvironment.

7.Themachinewasmodifiedorchangedinspecificationsaftertheincominginspectioniscomplete.

8.WhendefectivepartsreplacedfreeofchargewerenotreturnedtothelocationspecifiedbyYAMAHAorYAMAHA

salesrepresentativeswithin30days.

Note on network connections

ApreconditionfornetworkconnectionswiththeYAMAHAsurfacemountersandrelatedmachinesisthatsuch

connectionswillbeusedinclosednetworkscomprisedofaYAMAMHAsurfacemounter(orrelatedmachine)andanoff-

linePC.Thecustomermusttakeresponsibilityforconnectionstocompanyin-housenetworksandtoexternalnetworks.

PleaseacknowledgethatYAMAHAcanbearabsolutelynoresponsibilityfornetworksconfiguredbyotherthanjusta

YAMAMHAsurfacemounter(orrelatedmachine)andoff-linePCnorcanacceptresponsibilityforproblemsoccurring

duetonetworksettingsandconnections.

About USB memory devices

•UsetheUSBmemorydevice(suppliedwiththemachineorpurchasedfromYAMAHAsalesreps)specifiedby

YAMAHAMotorsCo.,Ltd.DonotuseanyothertypeofUSBmemorydevicewithYAMAHAsurfacemountersand

relatedmachines.AnyproblemsarisingfromusingotherthanthespecifiedUSBmemorydevicearenotcoveredby

ourwarranty.

•DonotconnectanyUSBdeviceotherthanthespecifiedUSBmemorydevicetotheUSBportonthemachine.Ifa

devicedriverforawrongdeviceisinstalled,thenthemachinemightnotworkcorrectly.Wetakenoresponsibilityfor

anyproblemscausedbyconnectingawrongorinappropriatedevice.
