1 Introduction, technical data User Manual SIPLACE S -25 HM 1.15 Overview of the modules - PCB conveyor Software Version SR.502.xx 01/2001 US Edition 46 1.15. 3 T echni cal dat a – dual conveyor sy stem 1 1 PCB form at (…

100%1 / 204
User Manual SIPLACE S-25 HM 1 Introduction, technical data
Software Version SR.502.xx 01/2001 US Edition 1.15 Overview of the modules - PCB conveyor
45
The conveyor belts are driven by DC motors. The lifting table near the center conveyor clamps the
PCBs in position. The width of the PCB conveyor can be adjusted either 1
– via the menu or
– using the line computer.
1
1.15.2 Technical data – single conveyor system
1
1
PCB format
(length x width)
50 mm x 50 mm to 460 mm x 460 mm
2" x 2" to 18" x 18"
Optionally:
50 mm x 50 mm up to 508 mm x 460 mm
(2" x 2" up to 20" x 18")
PCB thickness 0.5mm to 4.5mm
Max. PCB warpage On top: 4.5mm - PCB thickness
On bottom: 0.5mm + PCB thickness
Clearance on PCB underside 25mm (standard), 40mm (option)
PCB transport height 830mm ± 15mm (standard)
900mm ± 15mm (option)
930mm ± 15mm (option)
950mm ± 15mm (SMEMA: optional)
Fixed conveyor edge Right (standard), left (optional)
Type of interface Siemens (standard), (SMEMA: optional)
Component-free handling edge 3mm
PCB changeover time 2.5 s
Ink spot recognition possible
Automatic width adjustment possible
1 Introduction, technical data User Manual SIPLACE S-25 HM
1.15 Overview of the modules - PCB conveyor Software Version SR.502.xx 01/2001 US Edition
46
1.15.3 Technical data – dual conveyor system
1
1
PCB format
(length x width)
50mm x 50mm to 460mm x 216mm
(2" x 2" to 18" x 8.5")
Optionally:
50 mm x 50 mm up to 508mm x 216mm
(2" x 2" up to 20" x 8.5 ")
PCB thickness 0.5mm to 4.5mm
Max. PCB warpage On top: 4.5mm - PCB thickness
On bottom: 0.5mm + PCB thickness
Clearance on PCB underside 25mm (standard), 40mm (option)
PCB transport height 830mm ± 15mm (standard)
900mm ± 15mm (option)
930mm ± 15mm (option)
950mm ± 15mm (SMEMA: optional)
Stationary conveyor side Right (standard), left (optional)
Type of interface Siemens (standard), (SMEMA: optional)
Component-free handling edge 3mm
PCB changeover time 2.5 s
Type of transportation asynchronous
Components on each conveyor same
PCB width on each conveyor same
Ink spot recognition possible
Automatic width adjustment possible
User Manual SIPLACE S-25 HM 2 Operational Safety
Software Version SR.502.xx 01/2001 US Edition 2.1 Safety instructions
47
2 Operational Safety
2.1 Safety instructions
2.1.1 Conventions for the use of hazard symbols
This User Manual contains notes that must be observed to guarantee your personal safety and to
avoid damage to equipment. These notes are highlighted by warning triangles and are indicated
as follows according to the level of risk: 2
2
DANGER or 2
as used in this User Manual means that death, severe injury or considerable damage to equip-
ment may occur if the danger instructions are not followed. 2
2
WARNING or 2
as used in this User Manual means that death, severe injury or considerable damage to equip-
ment may occur if the warning instructions are not followed. 2
2
CAUTION or 2
as used in this User Manual means that slight injury or damage to equipment may occur if the cau-
tion instructions are not followed. 2
2
PLEASE NOTE 2
as used in this User Manual provides information on the product or indicates a part of the User
Manual that requires particular attention. 2
2.1.2 Qualified personnel
Qualified or adequately trained personnel means that these people are familiar with the setting up,
operation and maintenance of automatic placement systems and add-on devices and are suitably
qualified, e.g. 2
– have been trained, instructed or authorized to switch on and off, isolate, earth and identify elec-
trical circuits and system components in accordance with normal safety standards.
