2 Operational Safety User Manual SIPLACE S-25 HM 2.1 Safety instructions Software Version SR .502.xx 01/2001 US Edition 56 Fig. 2.1 - 3 Warning signs on the bas ic machine - part 3 T Dir ection o f PCB t ransport 2 2 Ite…
User Manual SIPLACE S-25 HM 2 Operational Safety
Software Version SR.502.xx 01/2001 US Edition 2.1 Safety instructions
55
Item 5 from the diagram 2.1 - 2
on page 53 showing the warning signs on the placement system
Feeder label (enlarged)
DANGER 2
Use only feeders, labeled as shown above, when feeding capacitors based on metal-powder (e.g.
tantalum). 2
Approved for
capacitors based on
metal-powder
Freigegeben für
Kondensatoren auf
Metallpulver-Basis
WARNING
WARNUNG
Use only approved feeders, labeled
as shown below, when feeding
capacitors based on metal-powder
(e.g. tantalum).
Kondensatoren auf Metallpulver-
Basis (z.B. Tantal) dürfen nur mit
folgendermaßen gekennzeichneten
Gurtförderern verarbeitet werden:
Approved for
capacitors based on
metal-powder
Freigegeben für
Kondensatoren auf
Metallpulver-Basis
2 Operational Safety User Manual SIPLACE S-25 HM
2.1 Safety instructions Software Version SR.502.xx 01/2001 US Edition
56
Fig. 2.1 - 3 Warning signs on the basic machine - part 3
T Direction of PCB transport 2
2
Item 1 from the diagram 2.1 - 3
showing the warning signs on the control unit on the basic machine 2
2
2
2
ACHTUNG
Handhabungsvorschriften
beachten
Elektrostatisch gefährdete
Bauelemente
ATTENTION
Electrostatic sensitive devices
Observe precautions for
handling
User Manual SIPLACE S-25 HM 2 Operational Safety
Software Version SR.502.xx 01/2001 US Edition 2.1 Safety instructions
57
Item 2 from the diagram 2.1 - 3
showing the warning signs on the control unit of the basic machine 2
2
2.1.6 Additional warning signs for the NAFTA region
Fig. 2.1 - 4 Warning signs on the basic machine - NAFTA region
WARNING! MAIN POWER VOLTAGE
Completely isolate the machine
before removing the protective cover.
Capacitor discharge time
tmin. = wait 0.3 minutes
