Overview 1-1 1 1.2.2. Applicable reels 1.2.2.1. The applicable reel to 8mm tape feeder Figure 1-10. Reel size 1.2.2.2. The applicable reel to the 16mm~56mm tape feeders Figure 1-1 1. Reel size for 16mm~56mm tape feeders
Samsung Pneumatic Tape Feeder Users' Manual
1-10
1.2. Tape Feeder Standard
1.2.1. Types of tape feeder and pitch
Table 1-1. Types of tape feeder and pitch
Model Product code
Width of
the tape
Pitch (mm)
NS T-1005 Tape Feeder SA0801004K 8 mm 2, 1005 only
NST-08P4 Tape Feeder SA0802004K 8 mm 4
NST08E-2P Tape Feeder SB0802006K 8 mm 2, Emboss tape only
NST08E-4P Tape Feeder SB0802007K 8 mm 4, Emboss tape only
1005 P- pneumatic disposal
type Feeder
SA0801001K 8 mm 2 (1005 only)
0603 P- pneumatic disposal
type Feeder
SB0800000K 8 mm 2 (0603 only)
08mm P- pneumatic disposal
type Feeder
SA0802001K 8 mm 4
1005 S-pneumatic Feeder SA0801000K 8 mm 2, 1005 only
08mm S-pneumatic Feeder SA0802000K 8 mm 4
12mm S-pneumatic Feeder SA0803000K 12mm 4, 8
16mm S-pneumatic Feeder SA0804000K 16mm 4, 8, 12
24mm S-pneumatic Feeder SA0805000K 24mm 8, 12, 16, 20
32mm S-pneumatic Feeder SA0806000K 32mm 8, 12, 16, 20, 24, 32
32mm A-pneumatic Feeder SA0809000K 32mm 12
44mm-L S-pneumatic Feeder SA0810000K 44mm 8, 12, 16, 20, 24
44mm-S S-pneumatic Feeder SA0811000K 44mm 16, 20, 24, 32, 40
56mm S-pneumatic Feeder SA0808000K 56mm 8, 12, 16, 20, 24, 32, 40
NST12E Tape Feeder SB0803002K 12mm 4, 8, 12
NST16E Tape Feeder SB0804002K 16mm 4, 8, 12
NST24E Tape Feeder SB0805002K 24mm 8, 12, 16, 20
NST32E-S Tape Feeder SB0806002K 32mm 16, 20, 24, 32, 40
NST32E-L Tape Feeder SB0806003K 32mm 8, 12, 16, 20, 24
NST44E-S Tape Feeder SB0807002K 44mm 16, 20, 24, 32, 40
NST44E-L Tape Feeder SB0807003K 44mm 8, 12, 16, 20, 24
NST56E Tape Feeder SB0809001K 56mm 8, 12, 16, 20, 24, 32, 40
Caution
Since the pickup point coordinate and width of the
12~56mm Nonstop Tape Feeder are different from those of
the existing Winding Type Feeder, their type must be
checked prior to use when using the feeders together.
Overview
1-11
1.2.2. Applicable reels
1.2.2.1. The applicable reel to 8mm tape feeder
Figure 1-10. Reel size
1.2.2.2. The applicable reel to the 16mm~56mm tape feeders
Figure 1-11. Reel size for 16mm~56mm tape feeders
Samsung Pneumatic Tape Feeder Users' Manual
1-12
1.2.3. Applicable components
Square chips, MELF, TR, SOP, PLCC, odd-type components
(For the 8mm Embossing Type Tape Feeder, the maximum length of T
2
is 2.5 mm.
for NST08E-4P, it is 3.5 mm. And for NST08E-4P, the maximum length of B1 is 4.35
mm. for NST08E-4P, it is 4.0 mm.)
Figure 1-12. Embossed Carrier Tape (8/12mm)
Figure 1-13. Embossed Carrier Tape (16/24mm)
