Overview
1-15
Operation of the Tape Feeder
2-1
Chapter 2. Operation of the Tape Feeder
2.1. Installing the Tape
Remove the locker by pressing the tape guide toward the direction of the arrow and
dismantle the gape guide.
Caution
Be sure to mount tapes in a safe place and make sure
that fingers don’t get stuck during the process.
Do not handle the feeder with excessive force.
Be sure to follow the specified sequence.
When transporting a large feeder, be careful not to
drop it.
Be sure to use a standard tape such as EIAJ or
JEDEL for the feeder.
Use only the right size component reel tape for the
feeder.
If the front part of tape guide(the area touching the
lock cover) is deformed, the Z axis position of
component pick up will be changed, which might
deteriorate the component adsorption rate. Take
special care when storing and using it.
Caution
Dismantling the feeder could cause damage or injury. If a
feeder malfunctions, please contact our designated C/S
company(STS).
