Overview 1-15
Samsung Pneumatic Tape Feeder Users' Manual
1-14
Caution
If TF-NST08, TF-P08, TF-S08 4mm pitch is used for
1005(2mm pitch), pick up error or component dumping
could occur often.
Be sure to use the feeder(2mm pitch) exclusively for
feeding 1005 chip and 0603 chip
Since TF-NST08E-4P and TF-NST08E-2P are used
exclusively for the Emboss Tape Feeder, pickup error
and other problems may occur if paper tape is used. In
such case, numerous components will be dumped.
Therefore, use only Emboss Tape.
Overview
1-15
