Operation of the T ape Feeder 2-3 Figur e 2-3. Lifting the tape guide of the 8mm non-stop tape feeder Ta p e Guide Locke r
Samsung Pneumatic Tape Feeder Users' Manual
2-2
Figure 2-1. Lifting the tape guide of the 8mm disposal type tape feeder
Figure 2-2. Lifting the tape guide of the 8mm tape feeder
The procedure lifting the tape guide is as follows. (8mm NST, 0603 disposal type tape
feeder)
1. Pull the locker outward lifting the locker upward slightly. (Refer to Figure 2-3, Figure
2-4)
2. Lift the tape guide upward. (Refer to Figure 2-3, Figure 2-4)
Tape Guide
Locke
r
Tape Guide
Locke
r
Operation of the Tape Feeder
2-3
Figure 2-3. Lifting the tape guide of the 8mm non-stop tape feeder
Ta
p
e Guide
Locke
r
Samsung Pneumatic Tape Feeder Users' Manual
2-4
Figure 2-4. Lifting the tape guide of the 0603 disposal type tape feeder
Tape Guide
Locke
r
