2 Brief Description
2.4 Tools and Equipment Required
Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V3 Stationäre Kamera Typ 25/33 (GigE) Stationary
Camera Type 25/33 (GigE) 03/2021
65
2.4 Tools and Equipment Required
●
ESD tape
●
Set of Allen keys
●
Set of screwdrivers
●
Universal pliers
●
Self-adhesive mounting base for cable ties (pack of 10 [03064015-xx])
●
Cable ties, B=2.5mm, L=102mm Panduit (pack of 10 [00308458-xx])
●
Microfiber cloth for cleaning optical assemblies
Service manual for your machine:
●
Service Manual SIPLACE SX1/SX2 V3 [DE:00198707‑xx] [EN:00198708‑xx]
Circuit diagrams for your machine:
●
Detailed circuit diagrams folder for SIPLACE SX1/SX2V3 (fromRxxxx)
[DEEN:00198680‑xx]
NOTICE
Second person
You might find it advisable to enlist the help of a second person for certain tasks.
The following additional tools will also be needed, depending on the camera type:
FC camera (type 25)
●
Long Allen key with T-handle (at least 30 cm) size 6
●
If no stationary camera has been fitted at location 1:
support plate assembly SP1 [03070836-xx]
The camera and reject bin are fitted onto this.
IC camera (type 33)
●
Allen key with T-handle size 5 and 6
●
Calibration tool version 3 [03010565-xx]
●
Assembly instructions "Verify component reject bin SIPLACE SX1/SX2 DE+EN"[00196615-xx]
2.5 Required Working Time
The complete installation will take approx. between 1 and 2 hours. The work time depends primar-
ily on the type of machine, the location and the camera configuration at the location.
2 Brief Description
2.5 Required Working Time
66 Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V3 Stationäre Kamera Typ 25/33 (GigE) Stationary
Camera Type 25/33 (GigE) 03/2021
3 Installation
3.1 General information
Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V3 Stationäre Kamera Typ 25/33 (GigE) Stationary
Camera Type 25/33 (GigE) 03/2021
67
3 Installation
3.1 General information
General information
●
IC cameras (SST33), FC cameras (SST25) or a coplan module can be installed at locations 1
and 2.
●
The SIPLACE CPP supports the IC camera.
●
The SIPLACE CPP must always be fitted in the top position (for CPP_H see service manual).
●
The SIPLACE TwinHead (TH) and the SIPLACE Very high force TwinHead (VHFTH) both
support the IC, FC camera and the 3D coplan module.
●
The IC camera is a prerequisite for installation of the FC camera or a 3D coplan module.
●
When fitting the IC camera, you need to fit adapter plates to the machine frame. These are
available for location 1 and location 2.
●
These adapter plates/mounting plates can accommodate both cameras (IC, FC), the 3D co-
plan module and the reject bin.
●
The installation height of the cameras is prescribed by the holes drilled in the adapter plate
and must be sight-checked after completion of the work, to prevent a head crash!
NOTICE
FC camera, 3D coplan module and SIPLACE TwinHead (TH) / SIPLACE Very high
force TwinHead (VHFTH)
An FC camera and a 3D coplan module are only possible together with a TwinHead. Only
one of these options can be fitted at the same location, meaning that either the FC camera
or the 3D coplan module can be used.
