SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD
MDOC-SOFT50283
24/62
The board program applicable to the selected production lot is loaded.
The production lot information of the loaded board program is displayed in the “Setup Board”
grids.
Item name Contents
Production Lot “Production lot” of the selected program list
Production Model “Production model (ASSY)” of the selected program list
Surface Info “Surface information” of the selected program list
4.1.3 Restrictions
There are no particular restrictions.
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD
MDOC-SOFT50283
25/62
4.2 Setup preparations corresponding to the production lot
[Export Required Parts List] function was added.
The parts information necessary for the setup is exported to the file.
When performing the setup with the production lot selected, use this file to prepare the parts
necessary for the setup.
4.2.1 Introduction
4.2.1.1 Preparations
When exporting the required parts list, the board program needs to be loaded beforehand.
For details, see “4.1 Program selection corresponding to the production lot”.
* The [Export Required Parts List] function can be used even when the board program is
loaded using a procedure other than the production lot.
4.2.1.2 Settings
There are no particular settings.
4.2.2 Operation procedure
Select a target line, and then click [File (F)] - [Export Required Parts List (R)...] menu.
* If there is no setup target in the “Line” field, [File (F)]-[Export Required Parts List (R)...] menu
becomes invalid.
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD
MDOC-SOFT50283
26/62
Specify a save place and file name, and then click the [Save (S)] button.
[Save (S)] button Exports the required parts list file with the specified file name.
[Cancel] button Cancels the export process.
Initial value
Save in (I) Work folder
File name (N)
RequiredPartsList_Line(line
number)_(YYYMMDD)_(HHMMSS).csv
Save as type (T) CSV (*.csv)
