SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD
MDOC-SOFT50283
28/62
4.2.3 File format
The following shows the contents of the required parts list file.
Line format
Line Description Remarks
1st line Version, 1
2nd line Production lot, Production lot, Separated by a comma like production lot.
* When the production lot is selected.
3rd line Board name Board name, Separated by a comma like board name.
4th line Header line Item name * See the column format.
5th line or later
Data line Required parts data * See the column format.
Column format
Column Contents (item name) Remarks
1st column Machine Name Machine name of line information
2nd column Cart/Magazine Position F1/F2/R1/R2/Magazine 1 to 4
3rd column Set No.
4th column Parts Name Parts name of board data
5th column Comment Parts comment of board data
6th column Feeder Type “8mm-tape”, etc.
7th column
Required Parts Count
Parts quantity required for one board (scheduled
quantity for the production plan).
8th column Parts Rack Number Rack number of parts ID information
9th column
Setup State
Completed/Uncompleted * Completed when the
process until the verify process is completed.
Example)
Version,1
Production Lot, KF1459, KF1460
Board Name, _PCB_LANE_1,_PCB_LANE_2
Machine Name,Cart/Magazine Position,Set No,Parts Name,Comment,Feeder Type,Required Parts…
YS24X_DL,F1,1,PARTS001,,8mmTape,5,TANA001,Complete
YS24X_DL,F1,5,PARTS00I,,24mmEmboss,1,,Incomplete
YS24X_DL,R1,110,PARTS002,,8mmTape,10,TANA002,Incomplete
YS24X_DL,Magazine1,1,PARTS011,,Auto TC,5,,Incomplete
YS24X_DL,Magazine1,2,PARTS012,,Auto TC,5,TANA012,Incomplete
YS24X_DL2,F1,1,PARTS001,,8mmTape,5,TANA001,Incomplete
YS24X_DL2,F1,5,PARTS00I,,24mmEmboss,1,,Incomplete
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD
MDOC-SOFT50283
29/62
4.2.4 Troubleshooting
Error
number
Contents Cause and corrective action
Ea6314
[Export Required Parts
List] was failed.
Cause
The folder/file may be write-protected.
The disk capacity at the save destination may be
insufficient.
Corrective action
Run [Export Required Parts List] again.
Check that the folder/file is not write-protected.
Check that the free disk space at the save
destination is sufficient.
4.2.5 Restrictions
There are no particular restrictions.
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD
MDOC-SOFT50283
30/62
4.3 Setup corresponding to the production lot
The setup work after loading the program is not changed.
* For details about the setup work, see the “Factory Tools S-Tool User’s Manual”.
