Software Version Description, Station Software 505.05 07/2008 Edition
18 of 150
3.2.3 Station computer
3.2.3.1 Station computer HF, HF/3
Name Simicro CPU076
CPU / clock frequency PIII / 866 MHz or 1,26 GHz
RAM memory 192 MB
Hard disk 6 GB
CD-ROM drive Yes
Floppy drive 3.5", 1.44 MB
Serial interfaces 2
Network 1 x 10/100Base-T
2 x 10Base-T
6-port hub
Table 3-2: Station computer hardware
3.2.3.2 Station computer S-25 HM, S-27 HM
Name SCENIC N 300
CPU / clock frequency PIV / 2.4 GHz
RAM memory 256 MB
Hard disk 40 GB
CD-ROM drive Yes
Floppy drive 3.5", 1.44 MB
Serial interfaces 2
Network 1 x 10/100Base-T
1 x 10Base-T
Table 3-3: Station computer hardware
3.2.3.3 Station computer HS-50, HS-50+, HS-60
Name SCENIC P 300
CPU / clock frequency PIV / 2.6 GHz
RAM memory 256 MB
Hard disk 40 GB
CD-ROM drive Yes
Floppy drive 3.5", 1.44 MB
Serial interfaces 2
Network 1 x 10/100Base-T
2 x 10Base-T
6-port hub
Table 3-4: Station computer hardware
Software Version Description, Station Software 505.05 07/2008 Edition
19 of 150
3.2.4 Machine controller
3.2.4.1 Machine controller HF, HF/3
Name Simicro CPU076
CPU / clock frequency PIII / 566 MHz
RAM memory 64 MB
Hard disk 6 GB
CD-ROM drive Yes
Floppy drive 3.5", 1.44 MB
Network 1 x 10/100Base-T
Table 3-5: Machine controller hardware
3.2.4.2 Machine controller S-25 HM, S-27 HM, HS-50, HS-50+, HS-60
Name Sicomp AMS – M54
CPU / clock frequency PI / 233 MHz
RAM memory 32 MB
Hard disk 504MB
CD-ROM drive No
Floppy drive 3.5", 1.44 MB
Network 1 x 10/100Base-T
Table 3-6: Machine controller hardware
Software Version Description, Station Software 505.05 07/2008 Edition
20 of 150
4 New features of station software 505.05
4.1 Revision of the Forced Setup Verification
The forced setup verification at the SIPLACE placement machine can be activated via SIPLACE Setup
Center. The forced setup verification monitors the verification status of individual tracks. Non-verified
tracks are disabled to force setup verification.
Forced setup verification is carried out with a connection to the station and requires successful setup
verification before production. This is implemented as follows: once an order or a packaging unit
changeover has been downloaded, the machine deactivates all divisions in which there are packaging
units for which no setup verification data has been received.
This means the line operator needs to successfully verify all the necessary components/packaging
units for the product before production can begin.
A detailed description can be found in the "Installation Manual SIPLACE Setup Center 3.0", item no.
00195642-xx.
4.1.1 Requirements
The forced setup verification requires SIPLACE Pro as of Version 5.0 and SIPLACE Setup Center as of
Version 3.0.
4.2 Shutterless feeder – Teaching pickup position
In some cases the PCB camera cannot reach the component pickup position in a shutterless feeder in
the middle. This can happen with shutterless feeder at the following machines and setup locations:
- S27
- HF/3, setup location 4
If the component pickup position is outside the traversing range but inside the traversing range inflated
by 5mm (field of view of the camera = 5mm), the PCB camera is moved to the nearest position and the
crosshairs are drawn excentric into the live image with an Offset in the direction of the component.
Otherwise an error message is displayed.
The functionality is supported on the following machines: S27 HM, HS50, HS60, HF, HF (as of A-001)
and HF/3.
4.2.1 Restrictions
On an S-27 HM machine it may be necessary to increase or decrease the y axis traversing range.
The functionality is not supported on S25 HM machines.
