3. Rough View Fig. 1 Light Source Device (TCM-X210) The -marked area is specially specified. Fig. 2 Lighting Unit (a) The -marked area shows the lighting (Front Lighting 3 Ring) for BGA/CSP component s. (b) It is necessa…

2. Specifications

0307-001 6 Tg0930-PM-SO

3. Rough View

Fig. 1 Light Source Device (TCM-X210)

The

-marked area is specially specified.

Fig. 2 Lighting Unit

(a) The

-marked area shows the lighting (Front Lighting 3

Ring) for BGA/CSP components.

(b) It is necessary to replace the light guide with the one exclu-

sively for the BGA/CSP lighting.

3. Rough View

0307-001 7 Tg0930-PM-SO

Note

Light Guide

4. Classification of Component Shapes

Component shapes are classified to distinguish each component library

data group.

The BGA/CSP components are included in the "Area Array" group.

BGA : Ball Grid Array

CSP : Chip Scale Package

LGA : Land Grid Array

Table 2

Component Shape Applicable Components (Reference)

BGA/CSP • Grid Array Components

BGA, LGA, CSP, and other similar-

shaped components

Fig. 3

0307-001 8 Tg0930-PM-SO

Note

4. Classification of Component Shapes
