1. What is Component Placement Machine?

The component placement machine places various types of electronic

components (called "Components" hereinafter) precisely on the speci-

fied spots of P.C.B. surfaces at high speed.

Fig. 1A1

1. What is Component Placement Machine?

0305-001 1-1 AIL01EOPP

Placement Head

Electronic Components

P.C.B.

2. Name and Function of Each Section

2.1 General View

Refer to the items described in "2.2", "2.3", and "2.4" for each section.

2.1.1 Front Side of Machine

Fig. 1A2 Front Side of Machine

2. Name and Function of Each Section

0305-001 1-2 AIL01EOPP

L Conveyor

Power Breaker

Front Safety Door

Front Service Panel

Front Operation Panel

Light Tower

[EMERGENCY STOP] Switch (Front)

2.1.2 Rear Side of Machine

Fig. 1A3 Rear Side of Machine

2.1 General View

0305-001 1-3 AIL01EOPP

R Conveyor

Light Tower

Rear Service Panel

Rear Operation Panel

Feeder Carriage Cover

[EMERGENCY STOP] Switch (Rear)

Ethernet LAN
