5 Operating the station software 5.1 Working with messages Administrator Guide / Administrator Handbuch / 管理员指南 IPC-HERMES-9852 - V1.2 05/2020 43 Display area - Selected message The text of the selected message is displa…
5 Operating the station software
5.1 Working with messages
42 Administrator Guide / Administrator Handbuch / 管理员指南 IPC-HERMES-9852 - V1.2 05/2020
Field Value/Meaning
→ From the upstream machine to this machine.
← From this machine to the upstream machine.
Output section
→ From this machine to the upstream machine
← From the downstream machine to this
machine.
Session# The number of the connection, in order to allow
the messages to be assigned.
Message The information transmitted.
Display all messages All the sent messages are shown in the list, irre-
spective of the message type.
Display only selected message types Opens a dialog box in which you can select
which messages are shown in the list. See also
5.1.3 "Selection of message types" [}44]
Display area - Status
Describes the current communication status between the communication end point for the current
machine selected on the tab (this machine) and the corresponding communication end point (Peer)
of the upstream or downstream machine.
Icon Value/Meaning
A board is available, the receiving machine is
ready.
A board is available, the receiving machine is
not ready.
Handshake: Establishment of connection
No board is available, the receiving machine is
ready.
No board is available, the receiving machine is
not ready.
There is currently no connection between the
two communication partners.
The conveyors of both machines are running.
The conveyor of the passing machine is run-
ning.
The conveyor of the receiving machine is run-
ning.
5 Operating the station software
5.1 Working with messages
Administrator Guide / Administrator Handbuch / 管理员指南 IPC-HERMES-9852 - V1.2 05/2020 43
Display area - Selected message
The text of the selected message is displayed.
Icon Value/Meaning
Allows you to search for a text string in the dis-
played message.
5.1.2 Vertical Channel
Display showing the messages sent between this machine and a higher-level system (client sys-
tem) using the IPC-HERMES-9852 protocol.
► In the toolbar, click Events (1) and select Hermes: Status and messages (2).
ð The IPC-HERMES-9852 – Events view is displayed.
► Select the Vertical channel tab (3).
Editing field - Messages
Field Value/Meaning
Time Time at which the message was issued.
Date and time: YYYY-MM-DD h:min:sec.msec
←→ Specifies the direction in which each message
was sent.
From a higher-level system (client system) to
this machine.
5 Operating the station software
5.1 Working with messages
44 Administrator Guide / Administrator Handbuch / 管理员指南 IPC-HERMES-9852 - V1.2 05/2020
Field Value/Meaning
From this machine to a higher-level machine.
Session# The number of the connection, in order to allow
the messages to be assigned.
Message The information transmitted.
Editing field - Sessions
Field Value/Meaning
Session# Number of the connection. If this number is
grayed out, the connection is not active.
Message Name of the higher-level system with which
messages were exchanged.
Display area - Selected message
The text of the selected message is displayed.
Icon Value/Meaning
Allows you to search for a text string in the dis-
played message.
See also
2 5.1.3 "Selection of message types" [}44]
5.1.3 Selection of message types
Select the messages to be displayed. This setting applies to both conveyor lanes and to the input
section or output section.
► Select the corresponding check box.
► Confirm your choice with Apply.
ð Restricts the messages that will be displayed to those selected here and closes the dialog
box.
