1 Introduction
1.1 General information
Administrator Guide / Administrator Handbuch / 管理员指南 IPC-HERMES-9852 - V1.2 05/2020 7
1 Introduction
This manual describes how to work with the communication protocol for SMT lines IPC-
HERMES-9852 version 1.2. We recommend that you read through it once you are familiar with the
main features in SIPLACE Pro and the station software. Here, you find all important information on
the relations and the individual procedures when working with the communication protocol for SMT
lines IPC-HERMES-9852 version 1.2.
The contents of this manual addresses the following user groups:
●
The line engineer
The line engineer has completed special training and is authorized to carry out tasks, such as
the creation of setup configurations and definition of inspection parameters etc.
●
The service engineer
Persons of this class have been trained to carry out servicing work, to set up machines and to
change the setup of machines.
CAUTION
Trained and qualified personnel
Only people with the appropriate training for the specific software part may carry out tasks
on the machine. All tasks must be carried out by trained and qualified personnel. All warn-
ing, caution and danger notes MUST be observed!
CAUTION
Contents of this manual
We would like to draw your attention to the fact that the contents of these manuals are not
part of a previous or existing agreement, commitment or legal contract, neither is this inten-
ded to modify one of the above. All obligations of ASM Assembly Systems GmbH & Co. KG
may be taken from the appropriate sales contract, which also contains a complete and valid
warranty agreement. These contractual statements are neither extended nor restricted by
this manual.
1.1 General information
1.1.1 Legend
This document uses the following symbols and notes for your convenience.
Words in bold/italic
print
These refer to dialogs, dialog fields, menu items, and commands.
Step ... Includes all actions to do with a particular dialog. A dialog may be com-
posed of several actions (→).
► Requires an action (e.g. mouse click, open file)
Indicates a warning. The information is essential for successful working.
Indicates explanatory information.
1 Introduction
1.1 General information
8 Administrator Guide / Administrator Handbuch / 管理员指南 IPC-HERMES-9852 - V1.2 05/2020
1.1.2 ASM on the World Wide Web
Log in to our homepage at http://www.asm-smt.com.
► You can choose between the German and English version.
The different sections contain information about our products, services and contact persons.
In addition, registered customers can also access the SIPLACE User Group. Here you can call up
special information about our placement systems, e.g.
●
Technical documentation,
●
Technical information,
●
Spare parts lists etc.
Registration for the user group is very simple:
► Click the Register link.
► Fill in the registration form and send it off to us.
Soon afterwards, you will receive your access authorization with USER ID and password.
1.1.3 Release History
Edition Changes
07/2018
●
First edition
11/2018
●
Update to version 1.1
●
Name change to IPC-HERMES-9852 and formal adaptations
●
Connection configuration in the LAN
●
Basic DEK configuration
●
Station software 712.0
04/2019
●
ASM Process Lens 2.5
●
IPC-HERMES-9852 with controlled production (e.g. barcode with con-
trolled production)
●
SIPLACE SX1/SX2 V1 support
●
Formal adjustments
05/2020
●
Update to version 1.2
●
SIPLACE SX1/SX2 V3 support
●
Vertical Channel
●
Formal adjustments
