7 Appendix
7.1 Error messages and error correction
50 Administrator Guide / Administrator Handbuch / 管理员指南 IPC-HERMES-9852 - V1.2 05/2020
40068 An invalid board ID has been signaled by the previous
machine
Cause of hazard Correction Action
IPC-HERMES-9852: The up-
stream machine reports that a
board has been passed. How-
ever, a different board with the
same board ID is already in this
machine.
The current board cannot be
assembled, otherwise this
would lead to data inconsist-
ency.
Remove the board from the up-
stream machine or cancel the
board by pressing Move board
into machine and cancel
board and use the drop-down
menu to specify where the
board is to be removed.
40069 The board did not leave the output section
Cause of hazard Correction Action
No acknowledgment was re-
ceived that the board reached
the input section of the down-
stream machine, even though
the board has left this machine.
Visually check where the board
is located.
Board is in the output sec-
tion: The board is still in the
output section or in an interme-
diate position between the two
machines.
Board removed by hand: The
board has been removed by
hand.
Board is completely in the in
the next machine: The board
is already completely in the
downstream machine.
First make sure that the board
can be moved freely in the con-
veyor.
Check if the laser light barrier
of the output section is set cor-
rectly and is fully functional.
Replace it, if necessary.
40070 IPC-HERMES-9852: Handover of board from previous
machine failed, message is missing
Cause Correction Action
IPC-HERMES-9852: The mes-
sage from the upstream
machine that the board is avail-
able was not received.
Visually check that the board is
fully located in the input section
and confirm that you have done
so by pressing the relevant but-
ton.
Board is in the input sec-
tion:Moves the board onwards
and starts production of the
board.
Board removed by hand: The
board has been removed by
hand.
40071 IPC-HERMES-9852: Handover of board to the next machine
failed, message is missing
Cause Correction Action
IPC-HERMES-9852: The mes-
sage from the downstream
machine that it is ready has not
been received.
Visually check that the board is
already located in the down-
stream machine and confirm
that you have done so by
pressing the relevant button.
Board is in the in the next
machine: Starts production of
the board.
Board removed by hand: The
board has been removed by
hand.
51Administrator Guide / Administrator Handbuch / 管理员指南 IPC-HERMES-9852 - V1.2 05/2020
Inhaltsverzeichnis
Inhaltsverzeichnis
1 Einleitung.. 53
1.1 Allgemeines.. 53
1.1.1 Zeichenerklärung.. 53
1.1.2 ASM im Internet.. 54
1.1.3 Übersicht über die Ausgabestände.. 54
2 Was ist IPC-HERMES-9852.. 55
2.1 Einführung.. 55
2.2 IPC-HERMES-9852 Dokumentation.. 55
2.3 Systemanforderungen.. 55
2.4 Die wichtigsten Vorteile auf einen Blick.. 56
3 Konfiguration.. 57
3.1 Verbindungskonfiguration im LAN.. 57
3.1.1 Linienrechner als Router verwenden.. 58
3.1.2 symmedia Plug & Work Box Industrial als Router verwenden.. 58
3.1.3 symmedia Plug & Work Box als Router verwenden.. 60
3.1.4 Linux-Rechner als Router verwenden.. 61
3.1.4.1 firewalld.. 61
3.1.4.2 iptables.. 62
3.1.5 HPE Office Connect 1920S 8G (JL380A) als Router verwenden.. 63
3.1.6 Anderen Router verwenden.. 70
3.2 Verbindungkonfiguration in SIPLACE Pro.. 71
3.3 Verbindungskonfiguration an der SIPLACE Station.. 73
3.4 Verbindungskonfiguration für DEK Drucker.. 75
3.4.1 Basiskonfiguration.. 75
3.5 Verbindungskonfiguration für ASM ProcessLens.. 77
4 Arbeiten mit der Line Control GUI.. 81
4.1 Verbindungsansicht in der Line Control GUI.. 81
4.1.1 Gerätekonfiguration prüfen.. 82
4.1.2 Download der Gerätekonfiguration.. 83
4.2 Grafische Darstellungen.. 83
5 Bedienung an der Stationssoftware.. 85
5.1 Arbeiten mit Meldungen.. 85
5.1.1 Eingabe- und Ausgabesektion Transportspuren.. 85
5.1.2 Vertikaler Kanal.. 87
5.1.3 Auswahl von Meldungstypen.. 88
5.2 Breite der Leiterplatte aus den IPC-HERMES-9852 Daten übernehmen.. 89
6 Beschränkungen.. 91
7 Anhang.. 93
7.1 Fehlermeldungen und deren Behebung.. 93
