I NSTA LLATION M ANUAL L INE C OMPUTER LCL 50 3.04 L&A VERVIEW O 4.2 Inst alling the line computer sof tware LRL Linux (SuSE 9.0) 4.2.1 Overview Installation can be carried out from a number of differ ent initial s c…
L&A INSTALLATION MANUAL LINE COMPUTER LCL 503.04
NSTALLATION UPGRADE INSTRUCTIONS I /
4.1.6 Installing the SCO LCU CD under Linux
If the SCO line computer CD is read in on a Linux computer, the installation aborts with the message
«file not found».
L&A EA SUBJECT TO CHANGE WITHOUT PRIOR NOTICE 03.03.2005
RUPERT-MAYER-STR. 44
D-81359 M
UNICH SWIA_503.04_EN.DOC PAGE 8 / 75
INSTALLATION MANUAL LINE COMPUTER LCL 503.04 L&A
VERVIEW O
4.2 Installing the line computer software LRL Linux (SuSE 9.0)
4.2.1 Overview
Installation can be carried out from a number of different initial scenarios. Different activities with re-
spect to data backup and data conversion are necessary depending on the initial scenario.. The
table below provides an overview:
New hardware SCO 3.0 SCO 5.0 SuSE 7.3 SuSE 9.0
Action New installation Update
Data backup - X X (X) -
Boot from CD X X X - -
«Install options»
1
- - - X X
Data conversion X X X - -
ATTENTION
Since the first installation routine 2002, some components had been changed,
which had to be considered. Especially
the computer type Econel 30
the computer type Econel 40
the computer type Econel 50
the 19” monitor (flat screen)
The manual had been supplemented by using USB- and network printers. Also the
usage of the alternative filesytem «EXT3» had been included.
Before the installation is carried out, a data backup run must be performed.
When migrating from SCO 3.0, data must first be converted at least to 403 format. Then the
data can be backed up over the network, for example.
When migrating from SCO 5.0, it is recommended that data is backed up over the network.
The backup tool «SDH_Backup« cannot be used for backing up data for Linux.
When migrating from SuSE 7.3, it is recommended that data are backed up.
After the software has been installed, the data must be reloaded into the master data maintenance
system. Any further data conversion is carried out by re-installing the LRL software and selecting the
menu option «OPTIONS» / «Install options».
After data backup has been carried out, continue as follows:
in the event of a new installation, proceed with section 4.2.2 New installation
1
This means, to install the software use the function «Options» / «Install Options» from the application menu.
03.03.2005 SUBJECT TO CHANGE WITHOUT PRIOR NOTICE L&A EA
R
UPERT-MAYER-STR. 44
P
AGE 9 / 75 SWIA_503.04_EN.DOC D-81359 MUNICH
L&A INSTALLATION MANUAL LINE COMPUTER LCL 503.04
NSTALLING THE LINE COMPUTER SOFTWARE INUX U
I
LRL L (S SE 9.0)
in the event of an upgrade, proceed with section 4.2.4 Update: Installation via «Install Op-
tions»
in the event of a pure LCL installation, proceed with section 4.2.5 Installation entries of LCL
software installation
4.2.2 New installation
The following remarks should be considered during a new installation.
4.2.2.1 Econel 30
NOTE
When using an «Econel 30» system (these have both a DVD and a CD wri-
ter) the installation CD must be inserted into the CD writer drive!
4.2.2.2 Econel 40
Before starting the installation of «auteq Linux 9.0» onto an «Econel 40», you have to check and
maybe change the BIOS settings:
1. After switch on the computer, press the ‹Delete› key, to enter the setup.
2. Select the 2
nd
page «Advanced»
3. Select the menu entry «IDE-Configuration»
4. Change the setting S-ATA Mode [Native]
to S-ATA Mode [Legacy]
e.g. using the ⊕ key.
Now you can start the installation as described below. If you don’t change the BIOS settings, the in-
stallation will abort with the message:
Error:
No hard disks were found for the installation.
Please check your hardware!
OK
