5OM-1602 1-1 1 气路图及实际贴装图 1 103-003A(04100) 定位单元 ( 实际贴装图 ) 10 8 9 9 10 7 No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty 7 Solenoid V alve 1 8 Solenoid V alve 1 9 Cylinder 2 10 Cylinder 2
5OM-1602
1-10
气路图及实际贴装图
1103-003A(04100)
定位单元 ( 气路图 )
A
B
Pipe
６
６００mm
４
４０mm
４
４０mm
４
２６００mm
４
２６００mm
Positioning U/D Positioning Unit Lowering Prevention
Pipe
８
９００mm
６
１５０mm
６
２００mm
６
４００mm
６
３５０mm
６
２５００mm
６
２４００mm
A
B
Left Side Cylinder
Right Side Cylinder
Left Side Cylinder
Right Side Cylinder
４
１７０mm
４
１４０mm
B
A
A
B
B
A
B
A
EA
EB
P
EB
P
EA
2
1
3
7
9
9
2
5
4
8
10
10
From Main Body From Main Body
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
φ
6 1
2 Tube
φ
8 1
3 Union Y 2
4 Union Y 2
5 Tube
φ
4 1
7 Solenoid Valve 1
8 Solenoid Valve 1
9 Cylinder 2
10 Cylinder 2
5OM-1602
1-11
气路图及实际贴装图
1103-003A(04100)
定位单元 ( 实际贴装图 )
10
8
9
9
10
7
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
7 Solenoid Valve 1
8 Solenoid Valve 1
9 Cylinder 2
10 Cylinder 2
5OM-1602
1-12
气路图及实际贴装图
1103-003-(0800G)
吸嘴储料器 ( 气路图 )
8
4
5
6
2
3
9
1
Stocker 1 U/D
From Main Body
Shutter 1 Open / Close
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
φ
8 1
2 Tube
φ
6 1
3 Tube
φ
4 1
4 Solenoid Valve 1
5 Cylinder 1
6 Cylinder 1
8 Needle 1
9 Union Y 1
