5OM-1602 1-18 气路图及实际贴装图 5 5 6 9 2 11 10 10 10 1 2 11 12 12 1 2 11 12 1 7 8 3 Nozzle 3 Nozzle 2 Nozzle 1 Air IN V acuum Set up 1 103-001-(03G00) 多功能安装头部 ( 气路图 ) No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty 1 T …
5OM-1602
1-17
气路图及实际贴装图
1103-003
送料器安装台 ( 实际贴装图 )
3
4
2
6
5
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
2 Solenoid Valve 2
3 Speed Controller 4
4 Cylinder 2
5 Modular Unit 2
6 Air Connector Pin 2
5OM-1602
1-18
气路图及实际贴装图
5
5
6
9
2
11
10
10
10
1
2
11
12
12
1
2
11
12
1
7
8
3
Nozzle 3Nozzle 2Nozzle 1
Air IN
Vacuum
Set up
1103-001-(03G00)
多功能安装头部 ( 气路图 )
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
φ
6 1 11 Vacuum Sensor 3
2 Tube
φ
6 1 12 Vacuum Filter 3
3 Tube
φ
6 1
4 Tube
φ
6 1
5 Tube
φ
6 1
6 Tube
φ
8 1
7 Regulater 1
8 Union Y 1
9 Manifold Unit 1
10 Solenoid Valve Unit 3
5OM-1602
1-19
气路图及实际贴装图
NOZZLE1 NOZZLE2 NOZZLE3
7
10
11
12
1103-001-(03G00)
多功能安装头部 ( 实际贴装图 )
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
7 Regulater 1
10 Solenoid Valve Unit 3
11 Vacuum Sensor 3
12 Vacuum Filter 3
