5OM-1602 1-14 气路图及实际贴装图 1 103-003-(03J0C) 安装头部 ( 气路图 ) A V P R A P A V P A V P V alve Filter Rotary Joint F 8 Fitting F 8 F 4 F 8 Fitting F 6 Fitting F 4 Fitting F 4 Fitting V alve 3 2 1 4 5 6 From Main Body Robot Cable …
5OM-1602
1-13
气路图及实际贴装图
1103-003-(0800G)
吸嘴储料器 ( 实际贴装图 )
9
4
5
6
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
4 Solenoid Valve 1
5 Cylinder 1
6 Cylinder 1
9 Union Y
5OM-1602
1-14
气路图及实际贴装图
1103-003-(03J0C)
安装头部 ( 气路图 )
A
V
P
R
A
P
A
V
P
A
V
P
Valve
Filter
Rotary Joint
F8 Fitting
F8
F4
F8 Fitting
F6 Fitting
F4 Fitting
F4 Fitting
Valve
3
2
1
4
5
6
From Main Body
Robot Cable
Nozzle1 Nozzle2 Nozzle15
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
φ
4 1
2 Tube
φ
8 1
3 Solenoid Valve 1
4 Rotary Joint 1
5 Solenoid Valve 15
6 Filter 15
5OM-1602
1-15
气路图及实际贴装图
1103-003-(0320C)
安装头部 ( 实际贴装图 )
3
5
4
6
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Solenoid Valve 1
2 Rotary Joint 1
3 Solenoid Valve 15
4 Filter 15
