5OM-1602 2-7 传感器及负载配置图 1 103-003 安装头部布局 ( 整体 ) Electric Box Inside Head Rotation Section Head U/D Section Nozzle U/D Section Nozzle Selection Section Symbol Name Symbol Name
5OM-1602
2-6
传感器及负载配置图
1008-002
送料器推车布局
Y6913
B6302
M63
B6914,B6910
Cutter
Feeder Base
Symbol Name Symbol Name
M63 Cutter Axis Motor
B6302
Cutter Origin (-)
Y6913 Feeder Clamp
B6914 Feeder Clamp Lower Limit (Clamping)
B6910 Feeder Clamp Upper Limit (Unclamping)
5OM-1602
2-7
传感器及负载配置图
1103-003
安装头部布局 ( 整体 )
Electric Box Inside
Head Rotation Section
Head U/D Section
Nozzle U/D Section
Nozzle Selection Section
Symbol Name Symbol Name
5OM-1602
2-8
传感器及负载配置图
1103-002
安装头部布局 ( 电器设备箱 )
Y0902
Symbol Name Symbol Name
Y0902 Air Blow
