5OM-1602 2-9 传感器及负载配置图 1 103-002 安装头部布局 ( 安装头旋转部 ) U37 Y0401-Y0415 B0413R M31 B0413T Symbol Name Symbol Name U37 Slip Ring M31 Head Rotation (DD) Motor B0413T Linear Measure Sensor (Light Emission) B0413R Linear Measure …
5OM-1602
2-8
传感器及负载配置图
1103-002
安装头部布局 ( 电器设备箱 )
Y0902
Symbol Name Symbol Name
Y0902 Air Blow
5OM-1602
2-9
传感器及负载配置图
1103-002
安装头部布局 ( 安装头旋转部 )
U37
Y0401-Y0415
B0413R
M31
B0413T
Symbol Name Symbol Name
U37 Slip Ring
M31 Head Rotation (DD) Motor
B0413T
Linear Measure Sensor (Light Emission)
B0413R Linear Measure Sensor (Light Reception)
Y0401-Y0415 Vacuum Changeover Valve 1 to 15
5OM-1602
2-10
传感器及负载配置图
1103-002
安装头部布局 ( 吸嘴选择部 )
M32
B3101
Symbol Name Symbol Name
M32 Nozzle Selection (NS) Motor
B3101 Nozzle Selection Position Detection
