4-22 4 ■4.Hi11(IN) 地址 位数 名称 0000h 0 Device No. Bit0 0000h 1 Device No. Bit1 0000h 2 Device No. Bit2 0000h 3 Device No. Bit3 0000h 4 Device Added Information Bit 0 0000h 5 Device Added Information Bit 1 0000h 6 Device …
4-21
4
■3.Hi11(OUT)
地址 位数 名称
0000h 0 Head 1 Vacuum / Dispense Head 1 Vacuum
0000h 1 Head 1 Vacuum Break
0000h 2 Head 2 Vacuum / Dispense Head 2 Vacuum
0000h 3 Head 2 Vacuum Break
0000h 4 Head 3 Vacuum / Dispense Head 3 Vacuum
0000h 5 Head 3 Vacuum Break
0000h 6 Head 4 Vacuum / Dispense Head 4 Vacuum
0000h 7 Head 4 Vacuum Break
0001h 0 Head 5 Vacuum
0001h 1 Head 5 Vacuum Break
0001h 2 Head 6 Vacuum
0001h 3 Head 6 Vacuum Break
0001h 4 Head 7 Vacuum
0001h 5 Head 7 Vacuum Break
0001h 6 Head 8 Vacuum
0001h 7 Head 8 Vacuum Break
0002h 4 DP Head 1 Pressure On
0002h 5 DP Head 2 Pressure On
0002h 6 DP Head 3 Pressure On
0002h 7 DP Head 4 Pressure On
0003h 0 Laser Sensor 1 Light Off
0003h 1 Laser Sensor 1 Function Output
0003h 2 Laser Sensor 2 Light Off
0003h 3 Laser Sensor 2 Function Output
0003h 4 A/D Conversion Mode Bit0
0003h 5 A/D Conversion Mode Bit1
0003h 6 A/D Conversion Mode Bit2
0003h 7 A/D Conversion Mode Bit3
0004h 0 Side Light for Teach Camera: Start Delay Time Bit0
0004h 1 Side Light for Teach Camera: Start Delay Time Bit1
0004h 2 Side Light for Teach Camera: Start Delay Time Bit2
0004h 3 Side Light for Teach Camera: Start Delay Time Bit3
0004h 4 Side Light for Teach Camera: Start Delay Time Bit4
0004h 5 Side Light for Teach Camera: Start Delay Time Bit5
0004h 6 Side Light for Teach Camera: Start Delay Time Bit6
0004h 7 Side Light for Teach Camera: Start Delay Time Bit7
0005h 0 Side Light for Teach Camera: Start Delay Time Bit8
0005h 1 Side Light for Teach Camera: Start Delay Time Bit9
0005h 2 Side Light for Teach Camera: Start Delay Time Bit10
0005h 3 Side Light for Teach Camera: Start Delay Time Bit11
0005h 4 Side Light for Teach Camera: Start Delay Time Bit12
0005h 5 Side Light for Teach Camera: Start Delay Time Bit13
0005h 6 Side Light for Teach Camera: Start Delay Time Bit14
0005h 7 Side Light for Teach Camera: Start Delay Time Bit15
0006h 0
Coaxial Light for Teach Camera: Start Delay Time Bit0
0006h 1
Coaxial Light for Teach Camera: Start Delay Time Bit1
0006h 2
Coaxial Light for Teach Camera: Start Delay Time Bit2
0006h 3
Coaxial Light for Teach Camera: Start Delay Time Bit3
0006h 4
Coaxial Light for Teach Camera: Start Delay Time Bit4
0006h 5
Coaxial Light for Teach Camera: Start Delay Time Bit5
地址 位数 名称
0006h 6
Coaxial Light for Teach Camera: Start Delay Time Bit6
0006h 7
Coaxial Light for Teach Camera: Start Delay Time Bit7
0007h 0
Coaxial Light for Teach Camera: Start Delay Time Bit8
0007h 1
Coaxial Light for Teach Camera: Start Delay Time Bit9
0007h 2
Coaxial Light for Teach Camera: Start Delay Time Bit10
0007h 3
Coaxial Light for Teach Camera: Start Delay Time Bit11
0007h 4
Coaxial Light for Teach Camera: Start Delay Time Bit12
0007h 5
Coaxial Light for Teach Camera: Start Delay Time Bit13
0007h 6
Coaxial Light for Teach Camera: Start Delay Time Bit14
0007h 7
Coaxial Light for Teach Camera: Start Delay Time Bit15
000Bh 7 Teach Camera Trigger Output
000Ch 0 Outside Light for Teach Camera: Time Bit0
000Ch 1 Outside Light for Teach Camera: Time Bit1
000Ch 2 Outside Light for Teach Camera: Time Bit2
000Ch 3 Outside Light for Teach Camera: Time Bit3
000Ch 4 Outside Light for Teach Camera: Time Bit4
000Ch 5 Outside Light for Teach Camera: Time Bit5
000Ch 6 Outside Light for Teach Camera: Time Bit6
000Ch 7 Outside Light for Teach Camera: Time Bit7
000Dh 0 Outside Light for Teach Camera: Time Bit8
000Dh 1 Outside Light for Teach Camera: Time Bit9
000Dh 2 Outside Light for Teach Camera: Time Bit10
000Dh 3 Outside Light for Teach Camera: Time Bit11
000Dh 4 Outside Light for Teach Camera: Time Bit12
000Dh 5 Outside Light for Teach Camera: Time Bit13
000Dh 6 Outside Light for Teach Camera: Time Bit14
000Dh 7 Outside Light for Teach Camera: Time Bit15
000Eh 0 Outside Light for Teach Camera: PWM Bit0
000Eh 1 Outside Light for Teach Camera: PWM Bit1
000Eh 2 Outside Light for Teach Camera: PWM Bit2
000Eh 3 Outside Light for Teach Camera: PWM Bit3
000Eh 4 Outside Light for Teach Camera: PWM Bit4
000Eh 5 Outside Light for Teach Camera: PWM Bit5
000Eh 6 Outside Light for Teach Camera: PWM Bit6
000Eh 7 Outside Light for Teach Camera: PWM Bit7
0010h 0 Inside Light for Teach Camera: Time Bit0
0010h 1 Inside Light for Teach Camera: Time Bit1
0010h 2 Inside Light for Teach Camera: Time Bit2
0010h 3 Inside Light for Teach Camera: Time Bit3
0010h 4 Inside Light for Teach Camera: Time Bit4
0010h 5 Inside Light for Teach Camera: Time Bit5
0010h 6 Inside Light for Teach Camera: Time Bit6
0010h 7 Inside Light for Teach Camera: Time Bit7
0011h 0 Inside Light for Teach Camera: Time Bit8
0011h 1 Inside Light for Teach Camera: Time Bit9
0011h 2 Inside Light for Teach Camera: Time Bit10
0011h 3 Inside Light for Teach Camera: Time Bit11
0011h 4 Inside Light for Teach Camera: Time Bit12
0011h 5 Inside Light for Teach Camera: Time Bit13
0011h 6 Inside Light for Teach Camera: Time Bit14
4-22
4
■4.Hi11(IN)
地址 位数 名称
0000h 0 Device No. Bit0
0000h 1 Device No. Bit1
0000h 2 Device No. Bit2
0000h 3 Device No. Bit3
0000h 4 Device Added Information Bit0
0000h 5 Device Added Information Bit1
0000h 6 Device Added Information Bit2
0000h 7 Output Register Value Bit0
0001h 0 Output Register Value Bit1
0001h 1 Output Register Value Bit2
0001h 2 Output Register Value Bit3
0001h 3 Output Register Value Bit4
0001h 4 Input Register Value Bit0
0001h 5 Input Register Value Bit1
0001h 6 Input Register Value Bit2
0001h 7 Input Register Value Bit3
0002h 0 AZ-axis 1 OR+
0002h 1 AZ-axis 2 OR+
0002h 2 AZ-axis 3 OR+
0002h 3 AZ-axis 4 OR+
0002h 4 AZ-axis 5 OR+
0002h 5 AZ-axis 6 OR+
0002h 6 OR- 1 (X)
0002h 7 OR+ 1 (X)
0003h 4 Dispense Head 1 Fluid Shortage
0003h 5 Dispense Head 2 Fluid Shortage
0003h 6 Dispense Head 3 Fluid Shortage
0003h 7 Dispense Head 4 Fluid Shortage
0004h 0 Air Pressure: Head A1 / Air Pressure: Head A1 Bit 0
0004h 1 Air Pressure: Head A1 Bit 1
0004h 2 Air Pressure: Head A1 Bit 2
0004h 3 Air Pressure: Head A1 Bit 3
0004h 4 Air Pressure: Head A1 Bit 4
0004h 5 Air Pressure: Head A1 Bit 5
0004h 6 Air Pressure: Head A1 Bit 6
0004h 7 Air Pressure: Head A1 Bit 7
0005h 0 Air Pressure: Head A1 Bit 8
0005h 1 Air Pressure: Head A1 Bit 9
0005h 2 Air Pressure: Head A1 Bit 10
0005h 3 Air Pressure: Head A1 Bit 11
0005h 4 Air Pressure: Head A1 Bit 12
0005h 5 Air Pressure: Head A1 Bit 13
0005h 6 Air Pressure: Head A1 Bit 14
0005h 7 Air Pressure: Head A1 Bit 15
0006h 0 Air Pressure: Head A2 / Air Pressure: Head A2 Bit 0
0006h 1 Air Pressure: Head A2 Bit 1
0006h 2 Air Pressure: Head A2 Bit 2
0006h 3 Air Pressure: Head A2 Bit 3
0006h 4 Air Pressure: Head A2 Bit 4
<S20_3. Hi11 (OUT)>
地址 位数 名称
0011h 7 Inside Light for Teach Camera: Time Bit15
0012h 0 Inside Light for Teach Camera: PWM Bit0
0012h 1 Inside Light for Teach Camera: PWM Bit1
0012h 2 Inside Light for Teach Camera: PWM Bit2
0012h 3 Inside Light for Teach Camera: PWM Bit3
0012h 4 Inside Light for Teach Camera: PWM Bit4
0012h 5 Inside Light for Teach Camera: PWM Bit5
0012h 6 Inside Light for Teach Camera: PWM Bit6
0012h 7 Inside Light for Teach Camera: PWM Bit7
0018h 0 Trigger Register Bit0
0018h 1 Trigger Register Bit1
0018h 2 Trigger Register Bit2
0018h 3 Trigger Register Bit3
0018h 4 Trigger Register Bit4
0018h 5 Trigger Register Bit5
0018h 6 Trigger Register Bit6
0018h 7 Trigger Register Bit7
0019h 0 Trigger Register Bit8
0019h 1 Trigger Register Bit9
0019h 2 Trigger Register Bit10
0019h 3 Trigger Register Bit11
0019h 4 Trigger Register Bit12
0019h 5 Trigger Register Bit13
0019h 6 Trigger Register Bit14
0019h 7 Trigger Register Bit15
001Ah 0 Trigger Register Bit16
001Ah 1 Trigger Register Bit17
001Ah 2 Trigger Register Bit18
001Ah 3 Trigger Register Bit19
001Ah 4 Trigger Register Bit20
001Ah 5 Trigger Register Bit21
001Ah 6 Trigger Register Bit22
001Ah 7 Trigger Register Bit23
001Bh 0 Trigger Register Bit24
001Bh 1 Trigger Register Bit25
001Bh 2 Trigger Register Bit26
001Bh 3 Trigger Register Bit27
001Bh 4 Trigger Register Bit28
001Bh 5 Trigger Register Bit29
001Bh 6 Trigger Register Bit30
001Bh 7 Trigger Register Bit31
0026h 0 Head 9 Vacuum
0026h 1 Head 9 Vacuum Break
0026h 2 Head 10 Vacuum
0026h 3 Head 10 Vacuum Break
0026h 4 Head 11 Vacuum
0026h 5 Head 11 Vacuum Break
0026h 6 Head 12 Vacuum
0026h 7 Head 12 Vacuum Break
4-23
4
<S20_4. Hi11 (IN)>
地址 位数 名称
0006h 5 Air Pressure: Head A2 Bit 5
0006h 6 Air Pressure: Head A2 Bit 6
0006h 7 Air Pressure: Head A2 Bit 7
0007h 0 Air Pressure: Head A2 Bit 8
0007h 1 Air Pressure: Head A2 Bit 9
0007h 2 Air Pressure: Head A2 Bit 10
0007h 3 Air Pressure: Head A2 Bit 11
0007h 4 Air Pressure: Head A2 Bit 12
0007h 5 Air Pressure: Head A2 Bit 13
0007h 6 Air Pressure: Head A2 Bit 14
0007h 7 Air Pressure: Head A2 Bit 15
0008h 0 Air Pressure: Head A3 / Air Pressure: Head A3 Bit 0
0008h 1 Air Pressure: Head A3 Bit 1
0008h 2 Air Pressure: Head A3 Bit 2
0008h 3 Air Pressure: Head A3 Bit 3
0008h 4 Air Pressure: Head A3 Bit 4
0008h 5 Air Pressure: Head A3 Bit 5
0008h 6 Air Pressure: Head A3 Bit 6
0008h 7 Air Pressure: Head A3 Bit 7
0009h 0 Air Pressure: Head A3 Bit 8
0009h 1 Air Pressure: Head A3 Bit 9
0009h 2 Air Pressure: Head A3 Bit 10
0009h 3 Air Pressure: Head A3 Bit 11
0009h 4 Air Pressure: Head A3 Bit 12
0009h 5 Air Pressure: Head A3 Bit 13
0009h 6 Air Pressure: Head A3 Bit 14
0009h 7 Air Pressure: Head A3 Bit 15
000Ah 0 Air Pressure: Head A4 / Air Pressure: Head A4 Bit 0
000Ah 1 Air Pressure: Head A4 Bit 1
000Ah 2 Air Pressure: Head A4 Bit 2
000Ah 3 Air Pressure: Head A4 Bit 3
000Ah 4 Air Pressure: Head A4 Bit 4
000Ah 5 Air Pressure: Head A4 Bit 5
000Ah 6 Air Pressure: Head A4 Bit 6
000Ah 7 Air Pressure: Head A4 Bit 7
000Bh 0 Air Pressure: Head A4 Bit 8
000Bh 1 Air Pressure: Head A4 Bit 9
000Bh 2 Air Pressure: Head A4 Bit 10
000Bh 3 Air Pressure: Head A4 Bit 11
000Bh 4 Air Pressure: Head A4 Bit 12
000Bh 5 Air Pressure: Head A4 Bit 13
000Bh 6 Air Pressure: Head A4 Bit 14
000Bh 7 Air Pressure: Head A4 Bit 15
000Ch 0 Air Pressure: Head A5 / Air Pressure: Head A5 Bit 0
000Ch 1 Air Pressure: Head A5 Bit 1
000Ch 2 Air Pressure: Head A5 Bit 2
000Ch 3 Air Pressure: Head A5 Bit 3
000Ch 4 Air Pressure: Head A5 Bit 4
000Ch 5 Air Pressure: Head A5 Bit 5
地址 位数 名称
000Ch 6 Air Pressure: Head A5 Bit 6
000Ch 7 Air Pressure: Head A5 Bit 7
000Dh 0 Air Pressure: Head A5 Bit 8
000Dh 1 Air Pressure: Head A5 Bit 9
000Dh 2 Air Pressure: Head A5 Bit 10
000Dh 3 Air Pressure: Head A5 Bit 11
000Dh 4 Air Pressure: Head A5 Bit 12
000Dh 5 Air Pressure: Head A5 Bit 13
000Dh 6 Air Pressure: Head A5 Bit 14
000Dh 7 Air Pressure: Head A5 Bit 15
000Eh 0 Air Pressure: Head A6 / Air Pressure: Head A6 Bit 0
000Eh 1 Air Pressure: Head A6 Bit 1
000Eh 2 Air Pressure: Head A6 Bit 2
000Eh 3 Air Pressure: Head A6 Bit 3
000Eh 4 Air Pressure: Head A6 Bit 4
000Eh 5 Air Pressure: Head A6 Bit 5
000Eh 6 Air Pressure: Head A6 Bit 6
000Eh 7 Air Pressure: Head A6 Bit 7
000Fh 0 Air Pressure: Head A6 Bit 8
000Fh 1 Air Pressure: Head A6 Bit 9
000Fh 2 Air Pressure: Head A6 Bit 10
000Fh 3 Air Pressure: Head A6 Bit 11
000Fh 4 Air Pressure: Head A6 Bit 12
000Fh 5 Air Pressure: Head A6 Bit 13
000Fh 6 Air Pressure: Head A6 Bit 14
000Fh 7 Air Pressure: Head A6 Bit 15
0010h 0 Measured Height / Laser Sensor1 Data Bit0
0010h 1 Laser Sensor1 Data Bit1
0010h 2 Laser Sensor1 Data Bit2
0010h 3 Laser Sensor1 Data Bit3
0010h 4 Laser Sensor1 Data Bit4
0010h 5 Laser Sensor1 Data Bit5
0010h 6 Laser Sensor1 Data Bit6
0010h 7 Laser Sensor1 Data Bit7
0011h 0 Laser Sensor1 Data Bit8
0011h 1 Laser Sensor1 Data Bit9
0011h 2 Laser Sensor1 Data Bit10
0011h 3 Laser Sensor1 Data Bit11
0011h 4 Laser Sensor1 Data Bit12
0011h 5 Laser Sensor1 Data Bit13
0011h 6 Laser Sensor1 Data Bit14
0011h 7 Laser Sensor1 Data Bit15
0012h 0 Laser Sensor2 / Laser Sensor2 Data Bit0
0012h 1 Laser Sensor2 Data Bit1
0012h 2 Laser Sensor2 Data Bit2
0012h 3 Laser Sensor2 Data Bit3
0012h 4 Laser Sensor2 Data Bit4
0012h 5 Laser Sensor2 Data Bit5
0012h 6 Laser Sensor2 Data Bit6
