4-8 4 <S10_2. Mi11 (IN)> 地址位数名称 0012h 2 Fan(T op 1) Lock 0012h 3 Fan(T op 2) Lock 0012h 4 Fan(Regenerative Resistor 1) Lock 0012h 5 Fan(Regenerative Resistor 2) Lock 0012h 7 Fan(Y1 Motor) Lock 0013h 0 Fan(Y2 Moto…

4-7

■2.Mi11(IN)

地址位数名称

0000h 0 Device No. Bit0

0000h 1 Device No. Bit1

0000h 2 Device No. Bit2

0000h 3 Device No. Bit3

0000h 4 Device Added Information Bit0

0000h 5 Device Added Information Bit1

0000h 6 Device Added Information Bit2

0000h 7 Output Register Value Bit0

0001h 0 Output Register Value Bit1

0001h 1 Output Register Value Bit2

0001h 2 Output Register Value Bit3

0001h 3 Output Register Value Bit4

0001h 4 Input Register Value Bit0

0001h 5 Input Register Value Bit1

0001h 6 Input Register Value Bit2

0001h 7 Input Register Value Bit3

0002h 0 Y-axis OR-

0002h 1 Y-axis OR+

0002h 6 UPS Under Backup

0002h 7 UPS Battery Low

0003h 0 Board Available Input

0003h 1 Ready Input

0003h 2 Regenerative Resistor1 Thermo Alarm

0003h 3 Regenerative Resistor2 Thermo Alarm

0003h 4 Regenerative Resistor3 Thermo Alarm

0003h 7 Fixed Camera Illumi

0004h 0 SERVO(F) / READY(F)

0004h 1 CANCEL(F) / RESET(F)

0004h 2 START(F)

0004h 3 CYCLE STOP(F) / STOP(F)

0004h 4 RECOVERY(F) / CLEAR(F)

0004h 7 DOCKING(F) / (Right Front)

0005h 1 Tape Cutter Close (Right Front)

0005h 2 Tape Cutter Close (Left Front)

0005h 3 Tape Cutter Close (Right Rear)

0005h 4 Tape Cutter Close (Left Rear)

0005h 5 Y1 Regenerative Resistor Thermal Alarm

0005h 6 Y2 Regenerative Resistor Thermal Alarm

0005h 7 X Regenerative Resistor Thermal Alarm

0006h 0 SERVO(R) / READY(R)

0006h 1 CANCEL(R) / RESET(R)

0006h 2 START(R)

0006h 3 CYCLE STOP(R) / STOP(R)

0006h 4 RECOVERY(R) / CLEAR(R)

0006h 7 DOCKING(R) / (Right Rear)

0007h 1 CTF(Right Rear) Power Relay ON

0007h 3 CTF(Right Rear) Connector Check

0008h 4 CFB(F) / (Right Front) Lock (R)

0008h 5 CFB(F) / (Right Front) Lock (L)

0008h 6 CFB(F) / (Right Front) Check

地址位数名称

0008h 7 CFB(F) / (Right Front) Check 2

0009h 0 CFB(R) / (Right Rear) Lock (R)

0009h 1 CFB(R) / (Right Rear) Lock (L)

0009h 2 CFB(R) / (Right Rear) Check

0009h 3 CFB(R) / (Right Rear) Check 2

000Ah 0 ENABLE(F) / ACTIVE(F)

000Ah 1 ENABLE(R) / ACTIVE(R)

000Ah 2 CTF(Right Rear) Positioning

000Ah 3 CTF(Right Rear) Insert Complete (L)

000Ah 4 CTF(Right Rear) Insert Complete (R)

000Bh 2 Conveyor1 Alarm

000Bh 3 Conveyor2 Alarm

000Bh 4 Conveyor3 Alarm

000Ch 0 Entrance Sensor / PCB Sensor Left Front

000Ch 1 Entrance Buffer Arrival / PCB Sensor Left Rear

000Ch 2 PCB S Stopper On

000Ch 3 PCB S Stopper Off

000Ch 4

Exit Sensor / Exit Buffer Arrival / PCB Sensor Right

Front

000Ch 5 Exit Buffer Slowdown

000Ch 6 PCB L Stopper On

000Ch 7 PCB L Stopper Off

000Dh 0 Main Clamp Up / Push-up Plate Up

000Dh 1 Push-up Plate Down

000Dh 2

Quick Clamp Down (Front) / Quick Clamp Upper

Limit: Front Center

000Dh 3 Quick Clamp Upper Limit: Right Front

000Dh 4

Quick Clamp Down (Rear) / Quick Clamp Upper

Limit: Rear Center

000Dh 5

Support Pins under Conveyor Rail / Quick Clamp

Upper Limit: Right Rear

000Dh 7 RTS-1(R) sensor

000Eh 2 ANC A Open

000Eh 3 ANC A Close

000Eh 4

Entrance Buffer Slowdown / Quick Clamp Upper

Limit: Left Front

000Eh 5 Main Conveyor Slowdown L

000Eh 6 Quick Clamp Upper Limit: Left Rear

000Eh 7 Main Conveyor Arrival S

000Fh 0 Main Conveyor Slowdown S

000Fh 1 Main Conveyor Arrival L

000Fh 3 PCB Sensor Right Rear

0010h 0 EMG(F)

0010h 1 Front Cover OPEN Detection

0010h 2 Cover Lock On (F)

0010h 4 EMG(R)

0010h 5 Rear Cover OPEN Detection

0010h 6 Cover Lock On (R)

0011h 0 SERVO(1:ON) / SERVO ON State

0011h 1 Air Pressure Down (failure)

0012h 0 Fan(Bottom 1) Lock

0012h 1 Fan(Bottom 2) Lock

4-8

<S10_2. Mi11 (IN)>

地址位数名称

0012h 2 Fan(Top 1) Lock

0012h 3 Fan(Top 2) Lock

0012h 4 Fan(Regenerative Resistor 1) Lock

0012h 5 Fan(Regenerative Resistor 2) Lock

0012h 7 Fan(Y1 Motor) Lock

0013h 0 Fan(Y2 Motor) Lock

0013h 1 Fan(X Motor) Lock

0013h 2 Fan(X Beam) Lock

0014h 0 Exit Slowdown (U-turn Conveyor)

0014h 1 START SW (U-turn Conveyor Left)

0014h 2 PCB Vacuum Sensor

0014h 3 START SW (U-turn Conveyor Right)

0014h 4 Exit-Conveyor Width Sensor1

0014h 5 Exit-Conveyor Width Sensor2

0015h 4 SSI DO Port Check Bit0

0015h 5 SSI DO Port Check Bit1

0015h 6 SSI DO Port Check Bit2

4-9

■3.Hi11(OUT)

地址位数名称

0000h 0 Head 1 Vacuum / Dispense Head 1 Vacuum

0000h 1 Head 1 Vacuum Break

0000h 2 Head 2 Vacuum / Dispense Head 2 Vacuum

0000h 3 Head 2 Vacuum Break

0000h 4 Head 3 Vacuum / Dispense Head 3 Vacuum

0000h 5 Head 3 Vacuum Break

0000h 6 Head 4 Vacuum / Dispense Head 4 Vacuum

0000h 7 Head 4 Vacuum Break

0001h 0 Head 5 Vacuum

0001h 1 Head 5 Vacuum Break

0001h 2 Head 6 Vacuum

0001h 3 Head 6 Vacuum Break

0001h 4 Head 7 Vacuum

0001h 5 Head 7 Vacuum Break

0001h 6 Head 8 Vacuum

0001h 7 Head 8 Vacuum Break

0002h 4 DP Head 1 Pressure On

0002h 5 DP Head 2 Pressure On

0002h 6 DP Head 3 Pressure On

0002h 7 DP Head 4 Pressure On

0003h 0 Laser Sensor 1 Light Off

0003h 1 Laser Sensor 1 Function Output

0003h 2 Laser Sensor 2 Light Off

0003h 3 Laser Sensor 2 Function Output

0003h 4 A/D Conversion Mode Bit0

0003h 5 A/D Conversion Mode Bit1

0003h 6 A/D Conversion Mode Bit2

0003h 7 A/D Conversion Mode Bit3

0004h 0 Side Light for Teach Camera: Start Delay Time Bit0

0004h 1 Side Light for Teach Camera: Start Delay Time Bit1

0004h 2 Side Light for Teach Camera: Start Delay Time Bit2

0004h 3 Side Light for Teach Camera: Start Delay Time Bit3

0004h 4 Side Light for Teach Camera: Start Delay Time Bit4

0004h 5 Side Light for Teach Camera: Start Delay Time Bit5

0004h 6 Side Light for Teach Camera: Start Delay Time Bit6

0004h 7 Side Light for Teach Camera: Start Delay Time Bit7

0005h 0 Side Light for Teach Camera: Start Delay Time Bit8

0005h 1 Side Light for Teach Camera: Start Delay Time Bit9

0005h 2 Side Light for Teach Camera: Start Delay Time Bit10

0005h 3 Side Light for Teach Camera: Start Delay Time Bit11

0005h 4 Side Light for Teach Camera: Start Delay Time Bit12

0005h 5 Side Light for Teach Camera: Start Delay Time Bit13

0005h 6 Side Light for Teach Camera: Start Delay Time Bit14

0005h 7 Side Light for Teach Camera: Start Delay Time Bit15

0006h 0

Coaxial Light for Teach Camera: Start Delay Time Bit0

0006h 1

Coaxial Light for Teach Camera: Start Delay Time Bit1

0006h 2

Coaxial Light for Teach Camera: Start Delay Time Bit2

0006h 3

Coaxial Light for Teach Camera: Start Delay Time Bit3

0006h 4

Coaxial Light for Teach Camera: Start Delay Time Bit4

地址位数名称

0006h 5

Coaxial Light for Teach Camera: Start Delay Time Bit5

0006h 6

Coaxial Light for Teach Camera: Start Delay Time Bit6

0006h 7

Coaxial Light for Teach Camera: Start Delay Time Bit7

0007h 0

Coaxial Light for Teach Camera: Start Delay Time Bit8

0007h 1

Coaxial Light for Teach Camera: Start Delay Time Bit9

0007h 2

Coaxial Light for Teach Camera: Start Delay Time Bit10

0007h 3

Coaxial Light for Teach Camera: Start Delay Time Bit11

0007h 4

Coaxial Light for Teach Camera: Start Delay Time Bit12

0007h 5

Coaxial Light for Teach Camera: Start Delay Time Bit13

0007h 6

Coaxial Light for Teach Camera: Start Delay Time Bit14

0007h 7

Coaxial Light for Teach Camera: Start Delay Time Bit15

000Bh 7 Teach Camera Trigger Output

000Ch 0 Outside Light for Teach Camera: Time Bit0

000Ch 1 Outside Light for Teach Camera: Time Bit1

000Ch 2 Outside Light for Teach Camera: Time Bit2

000Ch 3 Outside Light for Teach Camera: Time Bit3

000Ch 4 Outside Light for Teach Camera: Time Bit4

000Ch 5 Outside Light for Teach Camera: Time Bit5

000Ch 6 Outside Light for Teach Camera: Time Bit6

000Ch 7 Outside Light for Teach Camera: Time Bit7

000Dh 0 Outside Light for Teach Camera: Time Bit8

000Dh 1 Outside Light for Teach Camera: Time Bit9

000Dh 2 Outside Light for Teach Camera: Time Bit10

000Dh 3 Outside Light for Teach Camera: Time Bit11

000Dh 4 Outside Light for Teach Camera: Time Bit12

000Dh 5 Outside Light for Teach Camera: Time Bit13

000Dh 6 Outside Light for Teach Camera: Time Bit14

000Dh 7 Outside Light for Teach Camera: Time Bit15

000Eh 0 Outside Light for Teach Camera: PWM Bit0

000Eh 1 Outside Light for Teach Camera: PWM Bit1

000Eh 2 Outside Light for Teach Camera: PWM Bit2

000Eh 3 Outside Light for Teach Camera: PWM Bit3

000Eh 4 Outside Light for Teach Camera: PWM Bit4

000Eh 5 Outside Light for Teach Camera: PWM Bit5

000Eh 6 Outside Light for Teach Camera: PWM Bit6

000Eh 7 Outside Light for Teach Camera: PWM Bit7

0010h 0 Inside Light for Teach Camera: Time Bit0

0010h 1 Inside Light for Teach Camera: Time Bit1

0010h 2 Inside Light for Teach Camera: Time Bit2

0010h 3 Inside Light for Teach Camera: Time Bit3

0010h 4 Inside Light for Teach Camera: Time Bit4

0010h 5 Inside Light for Teach Camera: Time Bit5

0010h 6 Inside Light for Teach Camera: Time Bit6

0010h 7 Inside Light for Teach Camera: Time Bit7

0011h 0 Inside Light for Teach Camera: Time Bit8

0011h 1 Inside Light for Teach Camera: Time Bit9

0011h 2 Inside Light for Teach Camera: Time Bit10

0011h 3 Inside Light for Teach Camera: Time Bit11

0011h 4 Inside Light for Teach Camera: Time Bit12
