4-34 4 2.4.1 7 段 LED 的详细显示内容 诊断 代码诊断内容 00C0 OS Boot 00C4 Operating System not found 00C8 Set up 00CC Advanced Legacy BIOS 20 Advanced Configuration and Power Interface (ACPI) 21 22 23 24 Advanced Host Controller Interfa…

100%1 / 148
4-33
4
2.4 动作确认用 LED
动作确认用LED
LED10 (7段LED)
LED11 (7段LED)
LED 21
LED 23
LED 47LED 25
LED 20
LED 22
LED 24
LED 4
LED 5
LED 3
LED 6
LED 9
LED 8
LED 7
45405-LF3-00
Ref.No
名称
LED
亮灯条件
LED3 ATA ACT
黄色 访问硬盘过程中亮灯
LED4 SUS STAT
红色 在 CPU 模块节电模式 ( 暂停状态 ) 下亮灯
LED5 THERMTRIP
红色 CPU 模块温度异常时亮灯
LED6 +5V STB
绿色 ATX 电源 +5V 待机的电压正常时亮灯
LED7 +12V
绿色 ATX 电源 +12V 的电压正常时亮灯
LED8 +5V
绿色 ATX 电源 +5V 的电压正常时亮灯
LED9 +3.3V
绿色 ATX 电源 +3.3V 的电压正常时亮灯
LED10 7SEG HI
字母数字
显示 CPU 模块的自我诊断状态
Windows 正常启动时变为 c。
LED11 7SEG LO
字母数字
显示 CPU 模块的自我诊断状态
Windows 正常启动时变为 0。
LED20 LINK VISION
黄色 建立 PCIExpressVISION 链接时亮灯
LED21 DMA VISION
黄色 传送 PCIExpressVISION 的图像数据 DMA 过程中亮灯
LED22 LINK MOTION
黄色 建立 PCIExpressMOTION 链接时亮灯
LED23 DMA MOTION
黄色 传送 PCIExpressMOTION 的轴数据 DMA 过程中亮灯
LED24 LINK IO
黄色 建立 PCIExpressIO 链接时亮灯
LED25 HEART
蓝色
系统正常时快速闪烁
系统异常时低速闪烁或灭灯或亮灯
LED47 DMA IO
黄色 始终灭灯
4-34
4
2.4.1 7 段 LED 的详细显示内容
诊断 代码诊断内容
00C0 OS Boot
00C4 Operating System not found
00C8 Set up
00CC Advanced Legacy BIOS
20
Advanced Configuration and Power Interface (ACPI)
21
22
23
24
Advanced Host Controller Interface (AHCI)25
26
28
Boot Manager
29
2A
2C
2E
2F Capsule Service
31 Console Splitter
32 Crisis Recovery
33 Crypto
34 USB Legacy
35 Data Hub
36 Device Path
37 Diagnostic Splash Screen / Diagnostic Summary Screen
38 Disk I/O
39 DXE IPL
3C Error Log
3D File System
3E Firmware Device
3F Firmware Volume
41 Flash Communication
43 Font
44 Graphics Console
45 HDD Password
46
Human Interface Infrastructure (HII)
47
48
49
4B
IDE
4D
4E Image Decoder / Image Display
4F Interrupt Controller
51 ISA Bus
52 Key Translation
53 Keyboard Controller
55 Legacy BIOS
57 Memory Test
58 Metronome
59 Monotonic Counter
诊断 代码诊断内容
5B OEM Activation
5C Disk Partition
5E PCI Bus
60 Progress Indicator
61 PS/2 Keyboard
62 PS/2 Mouse
64 Real Time Clock (RTC)
65 Runtime
67 S3 Save / S3 Resume
68
SCSI69
6A
6B CRC Extraction
6D
Security
70
71 Serial Port
72 Setup
73
SMBIOS
74
75
System Management Mode (SMM)76
77
79 Splash
7A SMI
7B Status Code
7C Trusted Platform Module (TPM)
7D Text Console
7E Watchdog Timer
80 Unicode
81 USB
82 USB (EHCI, xHCI) Controller
83
USB Mass Storage, USB Keyboard, USB Mouse
84
85 User Manager
87 Variable Service
88 VGA
90 SPI Flash
92
Super I/O
93
94 Hardware Monitor
98
CPLD, FPGA
99
A0 Platform Stage 0
A1 Platform Stage 1
A2 Platform Stage 2
A3 Platform Stage DXE
A4 Platform S3 Save
A5 Platform Flash
A6 Platform SMM
4-35
4
诊断 代码诊断内容
A7 Platform PCI
A8 Platform CSM
A9 Platform HII Advanced
AA Platform Setup
AC Always on always connected (AOAC)
B4 Intel Fast Flash Standby (iFFS)
B5 Integrated Clock Controller (ICC)
BA
Intel vPro
BB
BC
BD
BE
BF
C0
C1
C2
Processor
C3
C4
C5
C6
C7
C8
C9
Chipset
CA
CB
CC
CD
CE
CF
F0 Reset vector.
F1 Leaving SEC/Going to PEI.
F2 Entering PEI Dispatch.
F3 Exiting PEI Dispatch.
F4 Entering DXE IPL's normal boot path.
F5 Entering DXE IPL's S3 boot path.
F6 Exiting S3 boot path back to the OS.
F7 Entering DXE IPL's recovery boot path.
F8 Exiting DXE IPL to enter the DXE phase.
F9 Entering DXE Dispatch.
FA Exiting DXE Dispatch.
FB No permanent memory found at the end of PEI.
FC No DXE IPL found at the end of PEI.
FD No DXE found at end of DXE IPL.
FE Couldn't find the PPIs needed by DXE.
FF
Missing one or more architectural protocols at the end of
DXE.
