4-25
4
■6.FrontRight(IN)
地址 位数 名称
0000h 0 Device No. Bit0
0000h 1 Device No. Bit1
0000h 2 Device No. Bit2
0000h 3 Device No. Bit3
0000h 4 Device Added Information Bit0
0000h 5 Device Added Information Bit1
0000h 6 Device Added Information Bit2
0000h 7 Output Register Value Bit0
0001h 0 Output Register Value Bit1
0001h 1 Output Register Value Bit2
0001h 2 Output Register Value Bit3
0001h 3 Output Register Value Bit4
0001h 4 Input Register Value Bit0
0001h 5 Input Register Value Bit1
0001h 6 Input Register Value Bit2
0001h 7 Input Register Value Bit3
0002h 0 BOARD (F / Right Front) ID0
0002h 1 BOARD (F / Right Front) ID1
0002h 2 BOARD (F / Right Front) ID2
0002h 3 BOARD (F / Right Front) ID3
0002h 4 BOARD (F / Right Front) ID4
0002h 5 BOARD (F / Right Front) ID5
0002h 6 BOARD (F / Right Front) ID6
0002h 7 BOARD (F / Right Front) ID7
0003h 0 BOARD (F / Right Front) ID8
0003h 1 BOARD (F / Right Front) ID9
0003h 2 BOARD (F / Right Front) ID10
0003h 3 BOARD (F / Right Front) ID11
0003h 4 BOARD (F / Right Front) ID12
0003h 5 BOARD (F / Right Front) ID13
0003h 6 BOARD (F / Right Front) ID14
0003h 7 BOARD (F / Right Front) ID15
<S20_4. Hi11 (IN)>
地址 位数 名称
002Dh 7 Air Pressure: Head A11 Bit 15
002Eh 0
Air Pressure: Head A12 / Air Pressure: Head A12 Bit 0
002Eh 1 Air Pressure: Head A12 Bit 1
002Eh 2 Air Pressure: Head A12 Bit 2
002Eh 3 Air Pressure: Head A12 Bit 3
002Eh 4 Air Pressure: Head A12 Bit 4
002Eh 5 Air Pressure: Head A12 Bit 5
002Eh 6 Air Pressure: Head A12 Bit 6
002Eh 7 Air Pressure: Head A12 Bit 7
002Fh 0 Air Pressure: Head A12 Bit 8
002Fh 1 Air Pressure: Head A12 Bit 9
002Fh 2 Air Pressure: Head A12 Bit 10
002Fh 3 Air Pressure: Head A12 Bit 11
002Fh 4 Air Pressure: Head A12 Bit 12
002Fh 5 Air Pressure: Head A12 Bit 13
002Fh 6 Air Pressure: Head A12 Bit 14
002Fh 7 Air Pressure: Head A12 Bit 15
4-26
4
■7.FrontLeft(OUT)
地址 位数 名称
0008h 0 SSIDOBit0
0008h 1 SSIDOBit1
0008h 2 SSIDOBit2
■8.FrontLeft(IN)
地址 位数 名称
0000h 0 Device No. Bit0
0000h 1 Device No. Bit1
0000h 2 Device No. Bit2
0000h 3 Device No. Bit3
0000h 4 Device Added Information Bit0
0000h 5 Device Added Information Bit1
0000h 6 Device Added Information Bit2
0000h 7 Output Register Value Bit0
0001h 0 Output Register Value Bit1
0001h 1 Output Register Value Bit2
0001h 2 Output Register Value Bit3
0001h 3 Output Register Value Bit4
0001h 4 Input Register Value Bit0
0001h 5 Input Register Value Bit1
0001h 6 Input Register Value Bit2
0001h 7 Input Register Value Bit3
0002h 0 BOARD (Left Front) ID0
0002h 1 BOARD (Left Front) ID1
0002h 2 BOARD (Left Front) ID2
0002h 3 BOARD (Left Front) ID3
0002h 4 BOARD (Left Front) ID4
0002h 5 BOARD (Left Front) ID5
0002h 6 BOARD (Left Front) ID6
0002h 7 BOARD (Left Front) ID7
0003h 0 BOARD (Left Front) ID8
0003h 1 BOARD (Left Front) ID9
0003h 2 BOARD (Left Front) ID10
0003h 3 BOARD (Left Front) ID11
0003h 4 BOARD (Left Front) ID12
0003h 5 BOARD (Left Front) ID13
0003h 6 BOARD (Left Front) ID14
0003h 7 BOARD (Left Front) ID15
000Ch 4 SSI DI Bit4
■9.RearLeft(OUT)
地址 位数 名称
0000h 0 CTF(Left Rear) Cover Lock
0000h 1 CTF(Left Rear) Shutter Open
0000h 2 CTF(Left Rear) Setup Switch
0000h 3 CTF(Left Rear) Safety Relay Reset
0000h 4 CTF(Left Rear) Servo ON Permission
0000h 5
CTF(Left Rear) Pallet Height Detection Sensor(L) Permit
0000h 7
CTF(Left Rear) Pallet Height Detection Sensor(R) Permit
0001h 0 CTF(Left Rear) Barcode Reader Trigger On
0001h 1 CTF(Left Rear) Barcode Reader Timeout Set Bit0
0001h 2 CTF(Left Rear) Barcode Reader Timeout Set Bit1
0001h 3 CTF(Left Rear) Barcode Reader Timeout Set Bit2
0001h 4
CTF(Left Rear) Barcode Reader Receive Counter Clear
4-27
4
■10.RearLeft(IN)
地址 位数 名称
0000h 0 Device No. Bit0
0000h 1 Device No. Bit1
0000h 2 Device No. Bit2
0000h 3 Device No. Bit3
0000h 4 Device Added Information Bit0
0000h 5 Device Added Information Bit1
0000h 6 Device Added Information Bit2
0000h 7 Output Register Value Bit0
0001h 0 Output Register Value Bit1
0001h 1 Output Register Value Bit2
0001h 2 Output Register Value Bit3
0001h 3 Output Register Value Bit4
0001h 4 Input Register Value Bit0
0001h 5 Input Register Value Bit1
0001h 6 Input Register Value Bit2
0001h 7 Input Register Value Bit3
0002h 0 BOARD (Left Rear) ID0
0002h 1 BOARD (Left Rear) ID1
0002h 2 BOARD (Left Rear) ID2
0002h 3 BOARD (Left Rear) ID3
0002h 4 BOARD (Left Rear) ID4
0002h 5 BOARD (Left Rear) ID5
0002h 6 BOARD (Left Rear) ID6
0002h 7 BOARD (Left Rear) ID7
0003h 0 BOARD (Left Rear) ID8
0003h 1 BOARD (Left Rear) ID9
0003h 2 BOARD (Left Rear) ID10
0003h 3 BOARD (Left Rear) ID11
0003h 4 BOARD (Left Rear) ID12
0003h 5 BOARD (Left Rear) ID13
0003h 6 BOARD (Left Rear) ID14
0003h 7 BOARD (Left Rear) ID15
0004h 0 CTF(Left Rear) Elevator-axis ORG/OR-
0004h 1 CTF(Left Rear) Elevator-axis OR+
0004h 2 CTF(Left Rear) Pallet Transfer Area Sensor
0004h 3 CTF(Left Rear) Shutter Open
0004h 4 CTF(Left Rear) Shutter Close
0004h 7 CTF(Left Rear) Pallet Check in Stocker
0005h 1 CTF(Left Rear) Pallet Check on Elevator
0005h 2 CTF(Left Rear) Pallet Middle Position Sensor
0005h 4 CTF(Left Rear) Cover Close
0005h 5 CTF(Left Rear) Cover Lock
0005h 6 CTF(Left Rear) Setup Switch
0005h 7
CTF(Left Rear) Regenerative Resistor Thermal Sensor
0006h 0 CTF(Left Rear) Hook-axis ORG/OR-
0006h 1
CTF(Left Rear) Hook axis Advanced End Position Sensor
0006h 2 CTF(Left Rear) Servo ON State
0006h 6 CTF(Left Rear) Pallet Height Detection Sensor(L)
0006h 7 CTF(Left Rear) Pallet Height Detection Sensor(R)
地址 位数 名称
0007h 0
CTF(Left Rear) Barcode Reader Receive Counter Bit0
0007h 1
CTF(Left Rear) Barcode Reader Receive Counter Bit1
0007h 2
CTF(Left Rear) Barcode Reader Receive Counter Bit2
0007h 3
CTF(Left Rear) Barcode Reader Receive Counter Bit3
0007h 4
CTF(Left Rear) Barcode Reader Receive Counter Bit4
0007h 5 CTF(Left Rear) Barcode Reader is Sending Data
0007h 6 CTF(Left Rear) Barcode Reader Found No Barcode
0007h 7 CTF(Left Rear) Barcode Reader Receive Complete
■11.RearRight(OUT)
地址 位数 名称
0000h 0 CTF(Right Rear) Cover Lock
0000h 1 CTF(Right Rear) Shutter Open
0000h 2 CTF(Right Rear) Setup Switch
0000h 3 CTF(Right Rear) Safety Relay Reset
0000h 4 CTF(Right Rear) Servo ON Permission
0000h 5
CTF(Right Rear) Pallet Height Detection Sensor(L)
Permit
0000h 7
CTF(Right Rear) Pallet Height Detection Sensor(R)
Permit
0001h 0 CTF(Right Rear) Barcode Reader Trigger On
0001h 1 CTF(Right Rear) Barcode Reader Timeout Set Bit0
0001h 2 CTF(Right Rear) Barcode Reader Timeout Set Bit1
0001h 3 CTF(Right Rear) Barcode Reader Timeout Set Bit2
0001h 4
CTF(Right Rear) Barcode Reader Receive Counter
Clear
