4-6 4 <S10_1. Mi11 (OUT)> 地址位数名称 0022h 6 Diffuse Light for Fixed Camera 1: PWM Bit6 0022h 7 Diffuse Light for Fixed Camera 1: PWM Bit7 0024h 0 Coaxial Light for Fixed Camera 1: T ime Bit0 0024h 1 Coaxial Light fo…

4-5

<S10_1. Mi11 (OUT)>

地址位数名称

0012h 2 Conveyor3 Speed Data Bit2

0012h 3 Conveyor3 Speed Data Bit3

0012h 4 Conveyor3 Speed Data Bit4

0012h 5 Conveyor3 Speed Data Bit5

0012h 6 Conveyor3 Speed Data Bit6

0012h 7 Conveyor3 Speed Data Bit7

0016h 0 Side Light for Fixed Camera: Start Delay Time Bit0

0016h 1 Side Light for Fixed Camera: Start Delay Time Bit1

0016h 2 Side Light for Fixed Camera: Start Delay Time Bit2

0016h 3 Side Light for Fixed Camera: Start Delay Time Bit3

0016h 4 Side Light for Fixed Camera: Start Delay Time Bit4

0016h 5 Side Light for Fixed Camera: Start Delay Time Bit5

0016h 6 Side Light for Fixed Camera: Start Delay Time Bit6

0016h 7 Side Light for Fixed Camera: Start Delay Time Bit7

0017h 0 Side Light for Fixed Camera: Start Delay Time Bit8

0017h 1 Side Light for Fixed Camera: Start Delay Time Bit9

0017h 2 Side Light for Fixed Camera: Start Delay Time Bit10

0017h 3 Side Light for Fixed Camera: Start Delay Time Bit11

0017h 4 Side Light for Fixed Camera: Start Delay Time Bit12

0017h 5 Side Light for Fixed Camera: Start Delay Time Bit13

0017h 6 Side Light for Fixed Camera: Start Delay Time Bit14

0017h 7 Side Light for Fixed Camera: Start Delay Time Bit15

0018h 0

Diffuse Light for Fixed Camera: Start Delay Time Bit0

0018h 1

Diffuse Light for Fixed Camera: Start Delay Time Bit1

0018h 2

Diffuse Light for Fixed Camera: Start Delay Time Bit2

0018h 3

Diffuse Light for Fixed Camera: Start Delay Time Bit3

0018h 4

Diffuse Light for Fixed Camera: Start Delay Time Bit4

0018h 5

Diffuse Light for Fixed Camera: Start Delay Time Bit5

0018h 6

Diffuse Light for Fixed Camera: Start Delay Time Bit6

0018h 7

Diffuse Light for Fixed Camera: Start Delay Time Bit7

0019h 0

Diffuse Light for Fixed Camera: Start Delay Time Bit8

0019h 1

Diffuse Light for Fixed Camera: Start Delay Time Bit9

0019h 2

Diffuse Light for Fixed Camera: Start Delay Time Bit10

0019h 3

Diffuse Light for Fixed Camera: Start Delay Time Bit11

0019h 4

Diffuse Light for Fixed Camera: Start Delay Time Bit12

0019h 5

Diffuse Light for Fixed Camera: Start Delay Time Bit13

0019h 6

Diffuse Light for Fixed Camera: Start Delay Time Bit14

0019h 7

Diffuse Light for Fixed Camera: Start Delay Time Bit15

001Ah 0

Coaxial Light for Fixed Camera: Start Delay Time Bit0

001Ah 1

Coaxial Light for Fixed Camera: Start Delay Time Bit1

001Ah 2

Coaxial Light for Fixed Camera: Start Delay Time Bit2

001Ah 3

Coaxial Light for Fixed Camera: Start Delay Time Bit3

001Ah 4

Coaxial Light for Fixed Camera: Start Delay Time Bit4

001Ah 5

Coaxial Light for Fixed Camera: Start Delay Time Bit5

001Ah 6

Coaxial Light for Fixed Camera: Start Delay Time Bit6

001Ah 7

Coaxial Light for Fixed Camera: Start Delay Time Bit7

001Bh 0

Coaxial Light for Fixed Camera: Start Delay Time Bit8

001Bh 1

Coaxial Light for Fixed Camera: Start Delay Time Bit9

001Bh 2

Coaxial Light for Fixed Camera: Start Delay Time Bit10

001Bh 3

Coaxial Light for Fixed Camera: Start Delay Time Bit11

地址位数名称

001Bh 4

Coaxial Light for Fixed Camera: Start Delay Time Bit12

001Bh 5

Coaxial Light for Fixed Camera: Start Delay Time Bit13

001Bh 6

Coaxial Light for Fixed Camera: Start Delay Time Bit14

001Bh 7

Coaxial Light for Fixed Camera: Start Delay Time Bit15

001Ch 0 Side Light for Fixed Camera 1: Time Bit0

001Ch 1 Side Light for Fixed Camera 1: Time Bit1

001Ch 2 Side Light for Fixed Camera 1: Time Bit2

001Ch 3 Side Light for Fixed Camera 1: Time Bit3

001Ch 4 Side Light for Fixed Camera 1: Time Bit4

001Ch 5 Side Light for Fixed Camera 1: Time Bit5

001Ch 6 Side Light for Fixed Camera 1: Time Bit6

001Ch 7 Side Light for Fixed Camera 1: Time Bit7

001Dh 0 Side Light for Fixed Camera 1: Time Bit8

001Dh 1 Side Light for Fixed Camera 1: Time Bit9

001Dh 2 Side Light for Fixed Camera 1: Time Bit10

001Dh 3 Side Light for Fixed Camera 1: Time Bit11

001Dh 4 Side Light for Fixed Camera 1: Time Bit12

001Dh 5 Side Light for Fixed Camera 1: Time Bit13

001Dh 6 Side Light for Fixed Camera 1: Time Bit14

001Dh 7 Side Light for Fixed Camera 1: Time Bit15

001Eh 0 Side Light for Fixed Camera 1: PWM Bit0

001Eh 1 Side Light for Fixed Camera 1: PWM Bit1

001Eh 2 Side Light for Fixed Camera 1: PWM Bit2

001Eh 3 Side Light for Fixed Camera 1: PWM Bit3

001Eh 4 Side Light for Fixed Camera 1: PWM Bit4

001Eh 5 Side Light for Fixed Camera 1: PWM Bit5

001Eh 6 Side Light for Fixed Camera 1: PWM Bit6

001Eh 7 Side Light for Fixed Camera 1: PWM Bit7

0020h 0 Diffuse Light for Fixed Camera 1: Time Bit0

0020h 1 Diffuse Light for Fixed Camera 1: Time Bit1

0020h 2 Diffuse Light for Fixed Camera 1: Time Bit2

0020h 3 Diffuse Light for Fixed Camera 1: Time Bit3

0020h 4 Diffuse Light for Fixed Camera 1: Time Bit4

0020h 5 Diffuse Light for Fixed Camera 1: Time Bit5

0020h 6 Diffuse Light for Fixed Camera 1: Time Bit6

0020h 7 Diffuse Light for Fixed Camera 1: Time Bit7

0021h 0 Diffuse Light for Fixed Camera 1: Time Bit8

0021h 1 Diffuse Light for Fixed Camera 1: Time Bit9

0021h 2 Diffuse Light for Fixed Camera 1: Time Bit10

0021h 3 Diffuse Light for Fixed Camera 1: Time Bit11

0021h 4 Diffuse Light for Fixed Camera 1: Time Bit12

0021h 5 Diffuse Light for Fixed Camera 1: Time Bit13

0021h 6 Diffuse Light for Fixed Camera 1: Time Bit14

0021h 7 Diffuse Light for Fixed Camera 1: Time Bit15

0022h 0 Diffuse Light for Fixed Camera 1: PWM Bit0

0022h 1 Diffuse Light for Fixed Camera 1: PWM Bit1

0022h 2 Diffuse Light for Fixed Camera 1: PWM Bit2

0022h 3 Diffuse Light for Fixed Camera 1: PWM Bit3

0022h 4 Diffuse Light for Fixed Camera 1: PWM Bit4

0022h 5 Diffuse Light for Fixed Camera 1: PWM Bit5

4-6

<S10_1. Mi11 (OUT)>

地址位数名称

0022h 6 Diffuse Light for Fixed Camera 1: PWM Bit6

0022h 7 Diffuse Light for Fixed Camera 1: PWM Bit7

0024h 0 Coaxial Light for Fixed Camera 1: Time Bit0

0024h 1 Coaxial Light for Fixed Camera 1: Time Bit1

0024h 2 Coaxial Light for Fixed Camera 1: Time Bit2

0024h 3 Coaxial Light for Fixed Camera 1: Time Bit3

0024h 4 Coaxial Light for Fixed Camera 1: Time Bit4

0024h 5 Coaxial Light for Fixed Camera 1: Time Bit5

0024h 6 Coaxial Light for Fixed Camera 1: Time Bit6

0024h 7 Coaxial Light for Fixed Camera 1: Time Bit7

0025h 0 Coaxial Light for Fixed Camera 1: Time Bit8

0025h 1 Coaxial Light for Fixed Camera 1: Time Bit9

0025h 2 Coaxial Light for Fixed Camera 1: Time Bit10

0025h 3 Coaxial Light for Fixed Camera 1: Time Bit11

0025h 4 Coaxial Light for Fixed Camera 1: Time Bit12

0025h 5 Coaxial Light for Fixed Camera 1: Time Bit13

0025h 6 Coaxial Light for Fixed Camera 1: Time Bit14

0025h 7 Coaxial Light for Fixed Camera 1: Time Bit15

0026h 0 Coaxial Light for Fixed Camera 1: PWM Bit0

0026h 1 Coaxial Light for Fixed Camera 1: PWM Bit1

0026h 2 Coaxial Light for Fixed Camera 1: PWM Bit2

0026h 3 Coaxial Light for Fixed Camera 1: PWM Bit3

0026h 4 Coaxial Light for Fixed Camera 1: PWM Bit4

0026h 5 Coaxial Light for Fixed Camera 1: PWM Bit5

0026h 6 Coaxial Light for Fixed Camera 1: PWM Bit6

0026h 7 Coaxial Light for Fixed Camera 1: PWM Bit7

0028h 0 Side Light for Fixed Camera 2: Time Bit0

0028h 1 Side Light for Fixed Camera 2: Time Bit1

0028h 2 Side Light for Fixed Camera 2: Time Bit2

0028h 3 Side Light for Fixed Camera 2: Time Bit3

0028h 4 Side Light for Fixed Camera 2: Time Bit4

0028h 5 Side Light for Fixed Camera 2: Time Bit5

0028h 6 Side Light for Fixed Camera 2: Time Bit6

0028h 7 Side Light for Fixed Camera 2: Time Bit7

0029h 0 Side Light for Fixed Camera 2: Time Bit8

0029h 1 Side Light for Fixed Camera 2: Time Bit9

0029h 2 Side Light for Fixed Camera 2: Time Bit10

0029h 3 Side Light for Fixed Camera 2: Time Bit11

0029h 4 Side Light for Fixed Camera 2: Time Bit12

0029h 5 Side Light for Fixed Camera 2: Time Bit13

0029h 6 Side Light for Fixed Camera 2: Time Bit14

0029h 7 Side Light for Fixed Camera 2: Time Bit15

002Ah 0 Side Light for Fixed Camera 2: PWM Bit0

002Ah 1 Side Light for Fixed Camera 2: PWM Bit1

002Ah 2 Side Light for Fixed Camera 2: PWM Bit2

002Ah 3 Side Light for Fixed Camera 2: PWM Bit3

002Ah 4 Side Light for Fixed Camera 2: PWM Bit4

002Ah 5 Side Light for Fixed Camera 2: PWM Bit5

002Ah 6 Side Light for Fixed Camera 2: PWM Bit6

地址位数名称

002Ah 7 Side Light for Fixed Camera 2: PWM Bit7

002Ch 0 Diffuse Light for Fixed Camera 2: Time Bit0

002Ch 1 Diffuse Light for Fixed Camera 2: Time Bit1

002Ch 2 Diffuse Light for Fixed Camera 2: Time Bit2

002Ch 3 Diffuse Light for Fixed Camera 2: Time Bit3

002Ch 4 Diffuse Light for Fixed Camera 2: Time Bit4

002Ch 5 Diffuse Light for Fixed Camera 2: Time Bit5

002Ch 6 Diffuse Light for Fixed Camera 2: Time Bit6

002Ch 7 Diffuse Light for Fixed Camera 2: Time Bit7

002Dh 0 Diffuse Light for Fixed Camera 2: Time Bit8

002Dh 1 Diffuse Light for Fixed Camera 2: Time Bit9

002Dh 2 Diffuse Light for Fixed Camera 2: Time Bit10

002Dh 3 Diffuse Light for Fixed Camera 2: Time Bit11

002Dh 4 Diffuse Light for Fixed Camera 2: Time Bit12

002Dh 5 Diffuse Light for Fixed Camera 2: Time Bit13

002Dh 6 Diffuse Light for Fixed Camera 2: Time Bit14

002Dh 7 Diffuse Light for Fixed Camera 2: Time Bit15

002Eh 0 Diffuse Light for Fixed Camera 2: PWM Bit0

002Eh 1 Diffuse Light for Fixed Camera 2: PWM Bit1

002Eh 2 Diffuse Light for Fixed Camera 2: PWM Bit2

002Eh 3 Diffuse Light for Fixed Camera 2: PWM Bit3

002Eh 4 Diffuse Light for Fixed Camera 2: PWM Bit4

002Eh 5 Diffuse Light for Fixed Camera 2: PWM Bit5

002Eh 6 Diffuse Light for Fixed Camera 2: PWM Bit6

002Eh 7 Diffuse Light for Fixed Camera 2: PWM Bit7

0030h 0 Coaxial Light for Fixed Camera 2: Time Bit0

0030h 1 Coaxial Light for Fixed Camera 2: Time Bit1

0030h 2 Coaxial Light for Fixed Camera 2: Time Bit2

0030h 3 Coaxial Light for Fixed Camera 2: Time Bit3

0030h 4 Coaxial Light for Fixed Camera 2: Time Bit4

0030h 5 Coaxial Light for Fixed Camera 2: Time Bit5

0030h 6 Coaxial Light for Fixed Camera 2: Time Bit6

0030h 7 Coaxial Light for Fixed Camera 2: Time Bit7

0031h 0 Coaxial Light for Fixed Camera 2: Time Bit8

0031h 1 Coaxial Light for Fixed Camera 2: Time Bit9

0031h 2 Coaxial Light for Fixed Camera 2: Time Bit10

0031h 3 Coaxial Light for Fixed Camera 2: Time Bit11

0031h 4 Coaxial Light for Fixed Camera 2: Time Bit12

0031h 5 Coaxial Light for Fixed Camera 2: Time Bit13

0031h 6 Coaxial Light for Fixed Camera 2: Time Bit14

0031h 7 Coaxial Light for Fixed Camera 2: Time Bit15

0032h 0 Coaxial Light for Fixed Camera 2: PWM Bit0

0032h 1 Coaxial Light for Fixed Camera 2: PWM Bit1

0032h 2 Coaxial Light for Fixed Camera 2: PWM Bit2

0032h 3 Coaxial Light for Fixed Camera 2: PWM Bit3

0032h 4 Coaxial Light for Fixed Camera 2: PWM Bit4

0032h 5 Coaxial Light for Fixed Camera 2: PWM Bit5

0032h 6 Coaxial Light for Fixed Camera 2: PWM Bit6

0032h 7 Coaxial Light for Fixed Camera 2: PWM Bit7

4-7

■2.Mi11(IN)

地址位数名称

0000h 0 Device No. Bit0

0000h 1 Device No. Bit1

0000h 2 Device No. Bit2

0000h 3 Device No. Bit3

0000h 4 Device Added Information Bit0

0000h 5 Device Added Information Bit1

0000h 6 Device Added Information Bit2

0000h 7 Output Register Value Bit0

0001h 0 Output Register Value Bit1

0001h 1 Output Register Value Bit2

0001h 2 Output Register Value Bit3

0001h 3 Output Register Value Bit4

0001h 4 Input Register Value Bit0

0001h 5 Input Register Value Bit1

0001h 6 Input Register Value Bit2

0001h 7 Input Register Value Bit3

0002h 0 Y-axis OR-

0002h 1 Y-axis OR+

0002h 6 UPS Under Backup

0002h 7 UPS Battery Low

0003h 0 Board Available Input

0003h 1 Ready Input

0003h 2 Regenerative Resistor1 Thermo Alarm

0003h 3 Regenerative Resistor2 Thermo Alarm

0003h 4 Regenerative Resistor3 Thermo Alarm

0003h 7 Fixed Camera Illumi

0004h 0 SERVO(F) / READY(F)

0004h 1 CANCEL(F) / RESET(F)

0004h 2 START(F)

0004h 3 CYCLE STOP(F) / STOP(F)

0004h 4 RECOVERY(F) / CLEAR(F)

0004h 7 DOCKING(F) / (Right Front)

0005h 1 Tape Cutter Close (Right Front)

0005h 2 Tape Cutter Close (Left Front)

0005h 3 Tape Cutter Close (Right Rear)

0005h 4 Tape Cutter Close (Left Rear)

0005h 5 Y1 Regenerative Resistor Thermal Alarm

0005h 6 Y2 Regenerative Resistor Thermal Alarm

0005h 7 X Regenerative Resistor Thermal Alarm

0006h 0 SERVO(R) / READY(R)

0006h 1 CANCEL(R) / RESET(R)

0006h 2 START(R)

0006h 3 CYCLE STOP(R) / STOP(R)

0006h 4 RECOVERY(R) / CLEAR(R)

0006h 7 DOCKING(R) / (Right Rear)

0007h 1 CTF(Right Rear) Power Relay ON

0007h 3 CTF(Right Rear) Connector Check

0008h 4 CFB(F) / (Right Front) Lock (R)

0008h 5 CFB(F) / (Right Front) Lock (L)

0008h 6 CFB(F) / (Right Front) Check

地址位数名称

0008h 7 CFB(F) / (Right Front) Check 2

0009h 0 CFB(R) / (Right Rear) Lock (R)

0009h 1 CFB(R) / (Right Rear) Lock (L)

0009h 2 CFB(R) / (Right Rear) Check

0009h 3 CFB(R) / (Right Rear) Check 2

000Ah 0 ENABLE(F) / ACTIVE(F)

000Ah 1 ENABLE(R) / ACTIVE(R)

000Ah 2 CTF(Right Rear) Positioning

000Ah 3 CTF(Right Rear) Insert Complete (L)

000Ah 4 CTF(Right Rear) Insert Complete (R)

000Bh 2 Conveyor1 Alarm

000Bh 3 Conveyor2 Alarm

000Bh 4 Conveyor3 Alarm

000Ch 0 Entrance Sensor / PCB Sensor Left Front

000Ch 1 Entrance Buffer Arrival / PCB Sensor Left Rear

000Ch 2 PCB S Stopper On

000Ch 3 PCB S Stopper Off

000Ch 4

Exit Sensor / Exit Buffer Arrival / PCB Sensor Right

Front

000Ch 5 Exit Buffer Slowdown

000Ch 6 PCB L Stopper On

000Ch 7 PCB L Stopper Off

000Dh 0 Main Clamp Up / Push-up Plate Up

000Dh 1 Push-up Plate Down

000Dh 2

Quick Clamp Down (Front) / Quick Clamp Upper

Limit: Front Center

000Dh 3 Quick Clamp Upper Limit: Right Front

000Dh 4

Quick Clamp Down (Rear) / Quick Clamp Upper

Limit: Rear Center

000Dh 5

Support Pins under Conveyor Rail / Quick Clamp

Upper Limit: Right Rear

000Dh 7 RTS-1(R) sensor

000Eh 2 ANC A Open

000Eh 3 ANC A Close

000Eh 4

Entrance Buffer Slowdown / Quick Clamp Upper

Limit: Left Front

000Eh 5 Main Conveyor Slowdown L

000Eh 6 Quick Clamp Upper Limit: Left Rear

000Eh 7 Main Conveyor Arrival S

000Fh 0 Main Conveyor Slowdown S

000Fh 1 Main Conveyor Arrival L

000Fh 3 PCB Sensor Right Rear

0010h 0 EMG(F)

0010h 1 Front Cover OPEN Detection

0010h 2 Cover Lock On (F)

0010h 4 EMG(R)

0010h 5 Rear Cover OPEN Detection

0010h 6 Cover Lock On (R)

0011h 0 SERVO(1:ON) / SERVO ON State

0011h 1 Air Pressure Down (failure)

0012h 0 Fan(Bottom 1) Lock

0012h 1 Fan(Bottom 2) Lock
