Station Software 709.1 / Version Description Ausgabe 05/2016 Edition
32
5.2 Camera Systems and Component Ranges
Detailed information on the used camera systems and component ranges for the placement heads
can be found in the respective machine specifications and/or User Manuals of the placement
machines.
Station Software 709.1 / Version Description Ausgabe 05/2016 Edition
33
6 SIPLACE Software Environment
6.1 SIPLACE Pro Programming System Version 13.1
The SIPLACE Pro programming system version 13.1 supports the SIPLACE X-series, X-series S,
SX-series, DX-series, CA-series and TX-series placement machines with the 709.1 station
software version.
Compatible mode: SIPLACE Pro 12.x
NOTICE
For a detailed description of the programming system, see the SIPLACE Pro version
description and the online help system.
6.2 SIPLACE OIS Version 13.1
Software version 13.1 of the monitoring system SIPLACE OIS supports the SIPLACE X-series,
X-series S, SX-series, DX-series, CA-series and TX-series placement machines.
Compatible mode: SIPLACE OIS 12.x
NOTICE
A detailed description can be found in the software description "Getting started with OIS"
and the online help system for OIS.
6.3 SIPLACE Setup Center Version 8.1
Software version 8.1 of the SIPLACE Setup Center supports the SIPLACE X-series, X-series S,
SX-series, DX-series, CA-series and TX-series placement machines.
Compatible mode: SIPLACE Setup Center 7.x
NOTICE
A detailed description can be found in the software description "Getting started with
Setup Center" and the online help system for Setup Center.
Station Software 709.1 / Version Description Ausgabe 05/2016 Edition
34
6.4 SIPLACE Traceability Version 5.1
Software version 5.1 of SIPLACE Traceability supports the SIPLACE X-series, X-series S,
SX-series, DX-series, CA-series and TX-series placement machines.
Compatible mode: SIPLACE Traceability 4.x
NOTICE
A detailed description can be found in the "Traceability User Guide".
