Station Software 709.1 / Version Descript ion Ausgabe 05/2016 E dition 45 Verifying camera connections – No support for chec king 3D Coplan sensors . Conveyor motor v erification No support on X - series conveyors.
Station Software 709.1 / Version Description Ausgabe 05/2016 Edition
44
Conveyor Carrier X
– No travel range check.
– No pickup simulation.
– The Conveyor Carrier X uses one track on an X-table virtually. If the real table should be
completely occupied, the operator might have to remove a feeder from the table to create place
for the virtual feeder.
– No I-Placement mode.
– The SIPLACE Pro Optimizer does not consider the time it takes to fill up a tray with
components and change it.
Individual barcode fiducials
– Barcode fiducials on the component underside are not supported because in this case the
barcode is read before the component is picked up.
SIPLACE TX-Serie
– Smart Pin Support is not supported.
– 3D-Coplan option is not supported.
– Restricted travel range for Twin Head:
The right segment cannot reach 3 tracks on the left side of the table,
the left segment cannot reach 3 tracks on the right side of the table.
– Restricted travel range for C&P20 P placement head:
Tracks 1-2 cannot be reached on location 1.
Heavy Board mode per board side
– No barcode mode possible.
Self-healing fiducial recognition
– Increasing the search area will only have an impact on geometric fiducials and not on fiducial
pattern.
– The second measurement will not be executed if the tolerance of a fiducial position is restricted
by the "Limited Tolerances" value in SIPLACE Pro.
Virtual keyboard
Cannot be used in the following cases:
– Changing the assignment of activity level to a button (right mouse key)
– During operating system installation as well as during any other software installation requiring
operating system administrator login.
Independent Placement – 2-in-1 mode
Not applicable for single conveyor, synchronous mode, alternating placement or machines
equipped with Smart Pin Support.
Station Software 709.1 / Version Description Ausgabe 05/2016 Edition
45
Verifying camera connections
– No support for checking 3D Coplan sensors.
Conveyor motor verification
No support on X-series conveyors.
Station Software 709.1 / Version Description Ausgabe 05/2016 Edition
46
8 Corrected Errors
709.1 Station Software
The 709.1 station software version contains all error corrections of the previous 701.xx – 709.0
versions. Additionally, the following errors have been corrected in this version:
Error no. Error description
D1-111516301 The SMEMA: Pass/Fail parameter was not described.
D1-112728711
D1-115198501
D1-119120701
The feeder was missing but the GUI did not show the table in red.
D1-113686401 The table could not be moved out when the safety circuit was closed.
D1-114875001
D1-118828501
D1-122383301
D17832-9172
The station software hung up during teaching of fiducials.
D1-115043701
D1-115476401
D1-118997001
D1-119118758
30491 Communication problem with axis control processor
D1-115218001
D1-115255201
I/O module: when opening one of the covers, the Insert button, component
table 1 was also erroneously changed.
D1-115884501 Error message without any content.
D1-116310201 Y axis could not be referenced.
D1-116397001
D1-119172601
D1-121398301
D1-122613309
The interior lighting was not active immediately.
D1-116786301 The setup remained in the station.
D1-116794843 Communication problem with the axis controller during reference run.
D1-118250765 The software hung up after job change.
D1-118479301 ACT report was not adapted.
D1-118910904 The console hung up.
D1-118962293 The coplanarity laser module was not switched on; the placement head stayed
motionless without any error message.
D1-119118701 30619 Vacuum difference 3003 too small for nozzle of type
49, permitted minimum: 50
