Station Software 709.1 / Version Description Ausgabe 05/2016 Edition
45
Verifying camera connections
– No support for checking 3D Coplan sensors.
Conveyor motor verification
No support on X-series conveyors.
Station Software 709.1 / Version Description Ausgabe 05/2016 Edition
46
8 Corrected Errors
709.1 Station Software
The 709.1 station software version contains all error corrections of the previous 701.xx – 709.0
versions. Additionally, the following errors have been corrected in this version:
Error no. Error description
D1-111516301 The SMEMA: Pass/Fail parameter was not described.
D1-112728711
D1-115198501
D1-119120701
The feeder was missing but the GUI did not show the table in red.
D1-113686401 The table could not be moved out when the safety circuit was closed.
D1-114875001
D1-118828501
D1-122383301
D17832-9172
The station software hung up during teaching of fiducials.
D1-115043701
D1-115476401
D1-118997001
D1-119118758
30491 Communication problem with axis control processor
D1-115218001
D1-115255201
I/O module: when opening one of the covers, the Insert button, component
table 1 was also erroneously changed.
D1-115884501 Error message without any content.
D1-116310201 Y axis could not be referenced.
D1-116397001
D1-119172601
D1-121398301
D1-122613309
The interior lighting was not active immediately.
D1-116786301 The setup remained in the station.
D1-116794843 Communication problem with the axis controller during reference run.
D1-118250765 The software hung up after job change.
D1-118479301 ACT report was not adapted.
D1-118910904 The console hung up.
D1-118962293 The coplanarity laser module was not switched on; the placement head stayed
motionless without any error message.
D1-119118701 30619 Vacuum difference 3003 too small for nozzle of type
49, permitted minimum: 50
Station Software 709.1 / Version Description Ausgabe 05/2016 Edition
47
D1-119138702 Error handling for pickup error was incorrect.
D1-119138794
D1-119138746
The Detailed Error view on the GUI was confusing.
D1-119147347 33325 Field of view of camera is too small for
measurement (422)
D1-121385312 Conveyor fiducial positions got lost.
D1-121758201 No virtual keyboard was displayed as the machine data was to be stored.
D1-121829301 Vision dump files from the component camera could not be viewed at the
station.
D1-121840501 Message text was truncated because to long for the error field.
D1-122278301 After Auto recovery: Target position of the X-axis was outside the travel range.
D1-122383501 The machine stopped without any message.
D1-122441821 The cutting times at the tape cutter of the SW placement machine were
incorrect.
D1-122466612 The hardware could not be initialized.
D1-122631801 Incorrect request by the calibration tool during the brief calibration.
D1-122642201 The automatic recognition of the conveyor rail for the TX placement machine
was very difficult to see on the GUI.
D1-123205901 The Coplan computer was not shut down.
D17842-8811 Different placement time on Lane1 and Lane2 of the X4i placement machine.
D17987-3405 No error message was displayed when the 3D camera was disconnected from
the GCU.
D18032-15180 No report was generated when the tape cutters were tested.
D18104-501
D17958-9017
D18104-601
The omitted track could not be reset on the GUI.
Table 8-1: Corrected errors station software version 709.1
709.0 Hotfix 3
Error no. Error description
D1-112147301 The fiducial of a 2x8 mm feeder was not checked.
D1-115043701
D1-115476401
eSW: During booting there was often the error message 30491
Communication problem with axis control processor
.
D1-115757401 Machine could not pick up the gripper from the nozzle changer.
D1-119280601 Error message: 30619 Vacuum difference 0 mbar too small for
nozzle of type 3004
.
D1-121385312 After having configured a dual conveyor as single conveyor and back to dual
again there was a problem finding all the conveyor fiducials.
