Station Software 709.1 / Version Description Ausgabe 05/2016 Edition

8 Corrected Errors

709.1 Station Software

The 709.1 station software version contains all error corrections of the previous 701.xx – 709.0

versions. Additionally, the following errors have been corrected in this version:

Error no. Error description

D1-111516301 The SMEMA: Pass/Fail parameter was not described.

D1-112728711

D1-115198501

D1-119120701

The feeder was missing but the GUI did not show the table in red.

D1-113686401 The table could not be moved out when the safety circuit was closed.

D1-114875001

D1-118828501

D1-122383301

D17832-9172

The station software hung up during teaching of fiducials.

D1-115043701

D1-115476401

D1-118997001

D1-119118758

30491 Communication problem with axis control processor

D1-115218001

D1-115255201

I/O module: when opening one of the covers, the Insert button, component

table 1 was also erroneously changed.

D1-115884501 Error message without any content.

D1-116310201 Y axis could not be referenced.

D1-116397001

D1-119172601

D1-121398301

D1-122613309

The interior lighting was not active immediately.

D1-116786301 The setup remained in the station.

D1-116794843 Communication problem with the axis controller during reference run.

D1-118250765 The software hung up after job change.

D1-118479301 ACT report was not adapted.

D1-118910904 The console hung up.

D1-118962293 The coplanarity laser module was not switched on; the placement head stayed

motionless without any error message.

D1-119118701 30619 Vacuum difference 3003 too small for nozzle of type

49, permitted minimum: 50

Station Software 709.1 / Version Description Ausgabe 05/2016 Edition

D1-119138702 Error handling for pickup error was incorrect.

D1-119138794

D1-119138746

The Detailed Error view on the GUI was confusing.

D1-119147347 33325 Field of view of camera is too small for

measurement (422)

D1-121385312 Conveyor fiducial positions got lost.

D1-121758201 No virtual keyboard was displayed as the machine data was to be stored.

D1-121829301 Vision dump files from the component camera could not be viewed at the

station.

D1-121840501 Message text was truncated because to long for the error field.

D1-122278301 After Auto recovery: Target position of the X-axis was outside the travel range.

D1-122383501 The machine stopped without any message.

D1-122441821 The cutting times at the tape cutter of the SW placement machine were

incorrect.

D1-122466612 The hardware could not be initialized.

D1-122631801 Incorrect request by the calibration tool during the brief calibration.

D1-122642201 The automatic recognition of the conveyor rail for the TX placement machine

was very difficult to see on the GUI.

D1-123205901 The Coplan computer was not shut down.

D17842-8811 Different placement time on Lane1 and Lane2 of the X4i placement machine.

D17987-3405 No error message was displayed when the 3D camera was disconnected from

the GCU.

D18032-15180 No report was generated when the tape cutters were tested.

D18104-501

D17958-9017

D18104-601

The omitted track could not be reset on the GUI.

Table 8-1: Corrected errors station software version 709.1

709.0 Hotfix 3

Error no. Error description

D1-112147301 The fiducial of a 2x8 mm feeder was not checked.

D1-115043701

D1-115476401

eSW: During booting there was often the error message 30491

Communication problem with axis control processor

D1-115757401 Machine could not pick up the gripper from the nozzle changer.

D1-119280601 Error message: 30619 Vacuum difference 0 mbar too small for

nozzle of type 3004

D1-121385312 After having configured a dual conveyor as single conveyor and back to dual

again there was a problem finding all the conveyor fiducials.

Station Software 709.1 / Version Description Ausgabe 05/2016 Edition

D1-121699901

D1-121459201

If a feeder with pitch setting "0" (no information) was removed and inserted

again a wrong pitch value (<>0) was loaded.

D1-122294801 Message: 37800 Machine stopped due to too many repetitive

errors on segment 2

D1-122349801 The export of the GUI activity levels did not work if a password had been set.

D17936-759 In case of a track error (e.g. run out of components) and trying to omit this

component, all feeders of the table were listed and all could be selected.

D18055-2411 The automatic calibration of heads and cameras function did not work if

Coplan should be calibrated.

Table 8-2: Corrected errors 709.0 Hotfix 3

709.0 Hotfix 2

Error no. Error description

D1-114416401 The machine stopped without error message when the height of the tray was

not correct.

D1-115338699 Automatic pitch detection was executed for a 4 mm feeder although the

detection was not activated for this feeder type.

D1-117279506 The machine was searching for a fiducial in the wrong place.

D1-118060197 When the job changes, the support pins were not automatically returned to the

magazine.

D1-118158001 The pocket recognition failed during the auto pitch detection.

D1-118183801 Reference run for DLM4 head was sporadically not possible.

It worked again after making a Z-axis reference run for DLM4 manually.

D1-118549501 If you wanted to lay down the nozzles for gantry 1 (TH head) an error

message came up for gantry 2 (DLM4 head).

D1-118850801 The pickup angle on table 2 was not correct.

D1-118910949 An interrupted board did not move out of the machine.

D1-118928201 The machine stopped with the error message: 40024 Component

prevents required star reference run

D1-118963801 The z pickup position was smaller than the minimal allowed value.

D1-118995201 CLI was not working on the station (the threshold values were not set).

D1-119039732 The service positions 1 and 2 were not correct.

D1-119064834 When the board was loaded into the machine it stopped with this error

message: 42412 Move is not allowed due to possible

collision

D1-119067001 Within the single calibration the segment-/head-offsets were 0.

D1-119125201 The station ignored the "incomplete" flag of the component shape.

D1-119139610 Minimum Component Sensor Value for HeadCareStation and machine was

different.

D1-119170901 There was an "'unhandled exception" during production.
