PROFLOW TX Print Medium Demand Sensor Setting A 5mm ± 1mm ProFlow TX Module W ARNING View on Right Hand End of T ransfer Head A Securing Screw Print Medium Demand Sensor 4 1 5 2 6 3 20

100%1 / 50
PROFLOW
Drive Belt Tension
3 to 4kgs
Setting
ProFlow Module
WARNING
Securing Screws
in 4 posns
Tie-wrap
41 52 63
19
PROFLOW TX
Print Medium Demand Sensor
Setting A
5mm ± 1mm
ProFlow TX Module
WARNING
View on Right Hand End of Transfer Head
A
Securing
Screw
Print Medium
Demand Sensor
41 52 63
20
PROFLOW ATX
Print Medium Demand Sensor
Setting A
5mm ± 1mm
ProFlow ATX Module
WARNING
View on Left Hand End of Transfer Head
A
Adjustment
Screw
Print Medium
Demand Sensor
41 52 63
21
