SAFETY
2
Safety notices in the form of PROHIBITION, WARNING, CAUTION and MANDATORY labels are
placed on the printing machine and throughout this manual to alert the maintainer to possible
hazards which may cause physical injury or damage to equipment. Refer to the Technical
Reference manual for full definitions.
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING IN THE TOOLING
AREA OF THE MACHINE TO AVOID INJURY. THE FOILS ON THE FRONT AND REAR BOARD
CLAMPS ARE VERY SHARP.
WARNING
STRONG MAGNETIC FIELD. A STRONG MAGNETIC FIELD EXISTS IN THE VICINITY OF THE
CAMERA LINEAR MOTORS. THIS MAY PRESENT A HAZARD TO PERSONNEL OR EQUIPMENT.
PROHIBITION
ELECTROMAGNETIC FIELD. AN ELECTROMAGNETIC FIELD EXISTS WITHIN THE MACHINE
FROM THE CAMERA LINEAR MOTORS. THESE MAY PRESENT A HAZARD TO PEOPLE FITTED
WITH AN IMPLANTED CARDIAC DECVICE. THE MOTOR MANUFACTURER RECOMMENDS A SAFE
DISTANCE OF AT LEAST 15MM.
PROHIBITION
STRONG MAGNETIC FIELD. A STRONG MAGNETIC FIELD EXISTS IN THE VICINITY OF THE
CAMERA LINEAR MOTORS THAT REPRESENTS A SERIOUS HAZARD TO PEOPLE FITTED WITH
METALLIC PARTS.
))
((
MANDATORY
TOXIC CHEMICALS MAY BE PRESENT. EYE PROTECTION MUST BE WORN.
MANDATORY
TOXIC CHEMICALS MAY BE PRESENT. SAFETY GLOVES MUST BE WORN.
PROHIBITION
STRONG MAGNETIC FIELD. A STRONG MAGNETIC FIELD EXISTS IN THE VICINITY OF THE
CAMERA LINEAR MOTORS THAT MAY ACT UPON FERROUS OBJECTS WHOSE MOVEMENTS
COULD LEAD TO PERSONAL INJURY AND/OR DAMAGE TO THE MACHINE.
3
SAFETY
Descriptions for the symbols used in this guide are given below:
KEY
Highlights the relevant danger to personnel.
Details where the respective dimensions/forces are taken.
WARNING
4
1
5
2
63
Reference to the Technical Reference manual.
Recommended handy tips.
4
