{TzYG|˅Gn {TzYG|˅Gn 2-56 2.4.4.5 . Cable Box 分解图及零件表
2-55
附加装置
No. Part No. Part Name Q'ty
Service
Material
Remarks
1 FC29-001403A CASE-PANNEL [SM1-FWS-018] 1
2 FC30-005156A PLATE-CONTROL PANEL_FLMS 1
3 EP20-001031A SWITCH,ETC-SELETIC-S/W_DJR604-
6315(DWL);
1
{TzYG|˅Gn{TzYG|˅Gn
2-56
2.4.4.5.
Cable Box 分解图及零件表
2-57
附加装置
No. Part No. Part Name Q'ty
Service
Material
Remarks
1 FC29-001400A CASE-LEFT [SM1-FWS-012] 1
2 FC15-005417A COVER-CABLE BOX COVER_SM1-FWS-
023;FLMS
1
3 EP10-000156A MAGNET-[SM1-FWS-019] 1
4 HP06-000016A FITTING;PL0602,R1/4,12.4P 2 PL0602
5 HP09-002665A REGULATOR-AW20-02BG_SM1-FWS-
049;AW20-02BG
1 AW20-02BG
6 FC29-008805A HINGES-HINGE_SUS-304;FLMS 4 SUS304
7 M4x12L BUTTON HEAD CAP SCREW 10
8 M3x6L BUTTON HEAD CAP SCREW 2
