{TzYG|˅Gn {TzYG|˅Gn 2-58 2.4.4.6 . Part Panel 分解图及零件表
2-57
附加装置
No. Part No. Part Name Q'ty
Service
Material
Remarks
1 FC29-001400A CASE-LEFT [SM1-FWS-012] 1
2 FC15-005417A COVER-CABLE BOX COVER_SM1-FWS-
023;FLMS
1
3 EP10-000156A MAGNET-[SM1-FWS-019] 1
4 HP06-000016A FITTING;PL0602,R1/4,12.4P 2 PL0602
5 HP09-002665A REGULATOR-AW20-02BG_SM1-FWS-
049;AW20-02BG
1 AW20-02BG
6 FC29-008805A HINGES-HINGE_SUS-304;FLMS 4 SUS304
7 M4x12L BUTTON HEAD CAP SCREW 10
8 M3x6L BUTTON HEAD CAP SCREW 2
{TzYG|˅Gn{TzYG|˅Gn
2-58
2.4.4.6.
Part Panel 分解图及零件表
2-59
附加装置
No. Part No. Part Name Q'ty
Service
Material
Remarks
1 FC15-005419A COVER-PART PANEL COVER_SM1-FWS-025 1
2 FC30-005154A PLATE-PART PANEL_SM1-FWS-204;FLMS 1
3 EP05-001033A CONCENT-FLMS_SM1-FWS-062;FLMS,2 1 AC220V2P
4 EP06-002798A UPS/SMPS-SMPS1_RSP500-24 4
5 FC09-008078A BRACKET-SMPS BRK1_SM1-FWS-203;FLMS 4
6 FC07-003939A BLOCK-GND BLOCK_SM1-FWS-206;FLMS 1
7 EP03-001057A DUCT,CABLE-CABLE DUCT_30X40;FLMS 5
8 EP21-001032A BLOCK,TERMINAL-TERMINAL
BLOCK_KH6010;FLM
4
9 FC09-008079A BRACKET-PANEL1_BRK_SM1-FWS-205;FLMS 1
10 FC30-005155A PLATE-PANEL1_SM1-FWS-207 1
11 EP20-001032A SWITCH,ETC-S-S/W1_8216;FLMS 4
