{TzYG|˅Gn {TzYG|˅Gn 2-8 2.1.2.2 . Stage Assembly 分解图及零件表

2-7

附加装置

序号零件号元件名数量

1 FC15-002131A ELITE-COVER_R 1

2 FC29-000291 B-1008-15 2

3 FC30-001753A ELITE-DOOR_BASE 1

4 FC29-002809A ELITE-DOOR_HANDLE 1

5 FC15-002129A ELITE-COVER_FR 1

{TzYG|˅Gn{TzYG|˅Gn

2-8

2.1.2.2.

Stage Assembly分解图及零件表

2-9

附加装置

序号零件号元件名数量

1 J70811090A BASE 1

2 J1500028 PROFILE MOUNT 5

3 FC29-002659A ELITE-MIRROR_HOLDER 2

4 J71801205A ELITE-MIRROR_STAND 2

5 EP15-000006A COAX_PLATE 1

6 J70811084A SHUTTER_PLATE 1

7 J71801206A CLED-BASE 1

8 EP16-000038A COAXIAL_LED 1

9 J72801052A DIFFUSER 1

10 J6103005A HEX SUPPORT 4

11 J67551020A MIRROR 1

12 J73591001A TAPE_L 2

13 J73591002A TAPE_S 1

14 J67541028A COVER_GLASS 1

15 J70811095A POLE 2

16 FC29-002654A ELITE-HOLDER_MAIN 1

17 AM03-000868A LENS_ASSY 1

18 J71801209A ADJUST_HOLDER 1

19 J67511005A CAMERA_ASSY 1

20 J70811087A HOLDER_SUB 1
