CP-842E CP-842ME Operator ’ s Guide R Preliminary The manuals listed below are shipped with this machine. CP-842E/842ME Operator's Guide CP-842E/842ME System Reference CP-842E/842ME Mechanical Reference In order to …
CP-842E
CP-842ME
Operator’s Guide
R
Preliminary
The manuals listed below are shipped with this
machine.
CP-842E/842ME Operator's Guide
CP-842E/842ME System Reference
CP-842E/842ME Mechanical Reference
In order to operate this machine in the safest and
most efficient manner, please read the provided
manuals thoroughly and observe all instructions
and warnings.
Keep these manuals in an accessible location near
the machine to enable them to be easily used when
needed.
Copyrights
All rights regarding this manual are reserved by Fuji Machine Manufacturing Co., Ltd. This manu-
al may not, in whole or in part, be reproduced by any means (electronic, mechanical or otherwise),
or reused in any way, without the prior written permission of Fuji Machine Manufacturing Co., Ltd.
Trademark Rights
is a trademark of Fuji Machine Manufacturing Co., Ltd., and registered in the follow-
ing countries: Austria, Belgium, Denmark, Finland, France, Germany, Greece, Indonesia, Ireland,
Italy, Japan, Korea, Luxembourg, the Netherlands, Portugal, Spain, Sweden, the U.K., and the
U.S.A.
Windows NT is a trademark of Microsoft Corporation, USA.
UNLHA(32).DLL is a freeware product created by Micco.
Warranty and Liability
Fuji Machine Manufacturing Co., Ltd. accepts no responsibility for situations that may arise due to
any of the following:
• The use of third party parts.
• The use of non-genuine Fuji parts.
• Incorrect settings made by the customer.
• Improper use of Fuji equipment.
Notice
Fuji Machine Manufacturing Co., Ltd. accepts no responsibility for any situations that may arise as
a result of the use of this manual.
Fuji Machine Manufacturing Co., Ltd. reserves the right to change the content of this manual with-
out notice.
Every effort has been made to ensure that this manual is correct in every detail. However, please
contact Fuji in the unlikely event that errors or omissions are detected.
R
Table of Contents
About This Manual
Manual Structure........................................................................1
Notation Conventions Used in This Manual ..............................2
How to Read This Manual..........................................................3
Chapter 1: Machine Configuration
1.1 Component Names and Fucntions ..................................1-2
Machine Overview........................................................................1-2
<CP-842E> ........................................................................1-2
<CP-842ME>......................................................................1-4
Servo Control Axes ............................................................1-8
Machine Configuration ................................................................1-9
Part Placement System ............................................................1-10
Placing Head....................................................................1-10
Station 1 ~ 16 ..................................................................1-11
Part Supply System ..................................................................1-14
Feeder Pallet....................................................................1-14
Vision Processing System ........................................................1-14
Fiducial Mark Camera ......................................................1-14
Parts Camera ..................................................................1-14
Panel Transport System ............................................................1-15
Chapter 2: Starting and Stopping the Machine
2.1 Starting the Machine ........................................................2-2
Turning on the Power ..................................................................2-2
2.2 Prior to Cutting the Power ................................................2-3
Reject Parts ................................................................................2-3
Move Device Table(s) to Escape Position ..................................2-3
2.3 Cutting the Power..............................................................2-4
Table of Contents
Preliminary
iCP-842E/842ME Operator’s Guide
