Panels on the in-conveyor can be loaded to the in-carrier. To do this, set a
panel on the in-conveyor (Panel check sensor must be on), then perform the
procedure shown below.
Procedure
1. Select [Panel Loader] from the [Setup] section at the [Main]
screen.
2. Select [Loader Maintenance].
3. Select [In-carrier Pickup] at the [Panel Transport Position] sec-
tion.
4. Press the START button.
A panel on the in-carrier can be loaded to the main conveyor using the proce-
dure shown below.
Procedure
1. Select [Panel Loader] from the [Setup] section at the [Main]
screen.
2. Select [Loader Maintenance].
3. Select [Main Conveyor Pickup] at the [Panel Transport Position]
section.
4. Press the START button.
8.11 Loading Panels to the Main
Conveyor
8.10 Loading Panels to In-Carrier
Chapter 8: Production Support Functions
Preliminary
8-8 CP-842E/842ME Operator’s Guide
Panels on the main conveyor can be unloaded to the out-carrier using the pro-
cedure shown below.
Procedure
1.
Select [Panel Loader] from the [Setup] section at the [Main]
screen.
2. Select [Loader Maintenance].
3. Select [Out-carrier Pickup] at the [Panel Transport Position] sec-
tion.
4. Press the START button.
Panels on the out-carrier can be unloaded to the out-lifter using the procedure
shown below.
Procedure
1.
Select [Panel Loader] from the [Setup] section at the [Main]
screen.
2. Select [Loader Maintenance].
3.
Select [Out-lifter Pickup] at the [Panel Transport Position] sec-
tion.
4. Press the START button.
8.13 Unloading Panels to the Out-Lifter
8.12 UnloadingPanelstothe Out-Carrier
Chapter 8: Production Support Functions
Preliminary
8-9CP-842E/842ME Operator’s Guide
This command is used to return the scheduled production quantity count to
zero.
Procedure
1.
Select [Program] from the [Changeover] section at the [Main]
screen.
2. Select [Clear Completed Panels].
3.
Select [OK] at the dialog box.
8.14 Clearing the Production Quantity
Count
Chapter 8: Production Support Functions
Preliminary
8-10 CP-842E/842ME Operator’s Guide
