Chapter 8 Production Support Functions 8.1 Manual Operation of Servo Control Axes 8.2 Setting the Production Start Sequence 8.3 Loading a New Panel 8.4 Unloading Panels From the XY -table 8.5 Unloading All Panels 8.6 Mov…
Frequency
Once a month
Procedure
WARNING
Be sure to turn the 200V power off before performing this
procedure.
• Use a vacuum cleaner to remove the foreign objects from the machine inte-
rior.
• Use a dry cloth to wipe grease off of all areas not specified as lubrication
points.
Note: Do not use an air gun within the machine as dust or other small fragments
may be blown into other areas of the machine.
7.9 Cleaning the Inside of the Machine
Chapter 7: Maintenance
Preliminary
7-10 CP-842E/842ME Operator’s Guide
Chapter 8
Production Support Functions
8.1 Manual Operation of Servo Control Axes
8.2 Setting the Production Start Sequence
8.3 Loading a New Panel
8.4 Unloading Panels From the XY-table
8.5 Unloading All Panels
8.6 Moving to the Panel Loading/Unloading Position on the XY-Table
8.7 Panel Lifter Up/Down
8.8 Main Conveyor Clamping/Unclamping
8.9 Step Mode Panel Loading
8.10 Loading Panels to In-Carrier
8.11 Loading Panels to the Main Conveyor
8.12 Unloading Panels to the Out-Carrier
8.13 Unloading Panels to the Out-Lifter
8.14 Clearing the Production Quantity Count
8.15 Skipping Boards
8.16 Pass Mode Operation
8.17 Nozzle Skip
Preliminary
8-1CP-842E/842ME Operator’s Guide
It is possible to operate a servo control axis via a manual operation. This oper-
ation is called "inching".
Procedure
1. Select [JOG…] from the command bar at the bottom of any
screen.
2. Select the desired axis from the [Select Axis Set] section.
3. Move the servo axis as desired using the inching keys.
Note: Rapid inching can be performed by holding down the [F] key while
pressing the appropriate arrow key.
Changing the Rapid Inching Speed
Procedure
1. Select [JOG…] from the command bar at the bottom of any
screen.
2. Select the desired axis from the [Setting Speed] section.
3. Use the numeric keypad to input the speed (expressed as a per-
cent of the full speed of the servo axis).
Note: The inching speed cannot be changed by more than 5%.
4. Then press [OK].
8.1 Manual Operation of Servo Control Axes
Chapter 8: Production Support Functions
Preliminary
8-2 CP-842E/842ME Operator’s Guide
